Fujitsu RX2560 M1

Model RX2560 M1Part no. VFY:R2561SC020INEAN 4053162872509

98 specifications

Overview

Brand: Fujitsu
Category: Server
Model: RX2560 M1
Part numbers: VFY:R2561SC020IN, VFY:R2561SC020IN S26361-F3849-L520, VFY:R2561SC020IN S26361-F2567-D423, VFY:R2561SC020IN S26361-F2567-D413
EAN / UPC: 4053162872509, 4053026839976
Also known as: Fujitsu PRIMERGY RX2560 M1 server Rack Intel Xeon E5 v3 E5-2620V3 2.4 GHz 8 GB DDR4-SDRAM 450 W

98 specifications in 12 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Xeon E5 v3
Processor model	E5-2620V3
Processor frequency	2.4 GHz
Processor boost frequency	3.2 GHz
Processor cores	6
Processor cache	15 MB
Motherboard chipset	Intel® C612
Memory channels supported by processor	Quad
Number of processors installed	1
Thermal Design Power (TDP)	85 W
Processor cache type	Smart Cache
System bus rate	8 GT/s
Bus type	QPI
ECC supported by processor	Yes
Embedded options available	Yes
Execute Disable Bit	Yes
Idle States	Yes
Maximum internal memory supported by processor	768 GB
Maximum number of PCI Express lanes	40
Memory bandwidth supported by processor (max)	59 GB/s
Memory clock speeds supported by processor	1600,1866 MHz
Memory types supported by processor	DDR4-SDRAM
Number of QPI links	2
PCI Express configurations	x4, x8, x16
Physical Address Extension (PAE)	46 bit
Physical Address Extension (PAE)	Yes
Processor code	SR207
Processor codename	Haswell
Processor lithography	22 nm
Processor operating modes	64-bit
Processor package size	52.5 x 45 mm
Processor series	Intel Xeon E5-2600 v3
Processor socket	LGA 2011-v3
Processor threads	12
Scalability	2S
Stepping	R2
Supported instruction sets	AVX
Tcase	72.6 °C
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Specification	Value
On-board graphics card	No
On-board graphics card model	Not available

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
VGA (D-Sub) ports quantity	1

Specification	Value
CPU configuration (max)	2
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Demand Based Switching	Yes
Intel Enhanced Halt State	Yes
Intel Flex Memory Access	No
Intel Identity Protection Technology version	0.00
Intel Secure Key Technology version	1.00
Intel TSX-NI	No
Intel TSX-NI version	0.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	No
Intel® OS Guard	Yes
Intel® Secure Key	Yes
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	83352

Specification	Value
Redundant power supply (RPS) support	Yes
Power supply	450 W
Number of redundant power supplies installed	1
Number of main power supplies	1

Specification	Value
Integrated LAN	Yes
