RX2530 M6
Model RX2530 M6Part no. VFY:R2536SC210INEAN 4065221769651
32 specifications
- ProcessorIntel Xeon Silver
- Memory32 GB
- OSNo
- Weight18.2 kg
- Processor manufacturerIntel
- Number of HDDs supported8
Overview
- Processor
- Intel Xeon Silver
- Memory
- 32 GB
- OS
- No
- Weight
- 18.2 kg
- Processor manufacturer
- Intel
- Number of HDDs supported
- 8
- Brand
- Fujitsu
- Category
- Server
- Model
- RX2530 M6
- Part numbers
- VFY:R2536SC210IN, VFY:R2536SC510IN, VFY:R2536SX070BE, VFY:R2536SC060IN, VFY:R2536SC080IN, VFY:R2536SC090IN +4 more
- EAN / UPC
- 4065221769651, 4065221747666, 4065221792048, 4065221792123 +5 more
- Also known as
- Fujitsu PRIMERGY RX2530 M6 server Rack (1U) Intel Xeon Silver 4310 2.1 GHz 32 GB DDR4-SDRAM
Specifications
32 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon Silver |
| Processor generation | 3rd Generation Intel® Xeon® Scalable |
| Processor model | 4310 |
| Processor frequency | 2.1 GHz |
| Processor boost frequency | 3.3 GHz |
| Processor cache | 18 MB |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | DDR4-SDRAM |
| Memory clock speed | 3200 MHz |
| Memory slots | 32x DIMM |
| Maximum internal memory | 10 TB |
Storage
| Specification | Value |
|---|---|
| Number of HDDs supported | 8 |
| Supported HDD sizes | 2.5" |
| RAID support | Yes |
| Hot-Plug support | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 5 |
| VGA (D-Sub) ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
| Rack mounting | Yes |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Windows Server 2019 Datacenter Windows Server 2019 Standard Windows Server 2019 Essentials Hyper-V Server 2016 Windows Server 2016 Datacenter Windows Server 2016 Standard Windows Server 2016 Essentials Windows Storage Server 2016 Standard SUSE® Linux Enterprise Server 12 Red Hat® Enterprise Linux 8 |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 0 - 35 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84714100 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 482.2 mm |
| Depth | 807.5 mm |
| Height | 42.7 mm |
| Weight | 18.2 kg |
