Fujitsu PRIMERGY RX200S5 server
0 GB Rack (1U) Intel® Xeon® 5000 Sequence E5504 2 GHz 4 GB DDR3-SDRAM 770 W
Model RX200S5Part no. CFY:R2005SC251IN
111 specifications
- ProcessorIntel® Xeon® 5000 Sequence
- Memory4 GB
- Storage0 GB
- Weight18 kg
- Processor manufacturerIntel
- Network readyYes
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Memory
- 4 GB
- Storage
- 0 GB
- Weight
- 18 kg
- Processor manufacturer
- Intel
- Network ready
- Yes
- Brand
- Fujitsu
- Category
- Server
- Model
- RX200S5
- Part number
- CFY:R2005SC251IN
- Also known as
- Fujitsu PRIMERGY RX200S5 server 0 GB Rack (1U) Intel® Xeon® 5000 Sequence E5504 2 GHz 4 GB DDR3-SDRAM 770 W
Specifications
111 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | E5504 |
| Processor frequency | 2 GHz |
| Processor cores | 4 |
| Processor cache | 4 MB |
| Motherboard chipset | Intel® 5500 |
| Memory channels supported by processor | Triple |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 80 W |
| Processor cache type | Smart Cache |
| System bus rate | 4.8 GT/s |
| Bus type | QPI |
| CPU multiplier (bus/core ratio) | 15 |
| ECC supported by processor | Yes |
| Embedded options available | Yes |
| Execute Disable Bit | Yes |
| FSB Parity | No |
| Idle States | Yes |
| Maximum internal memory supported by processor | 144 GB |
| Maximum number of SMP processors | 2 |
| Memory bandwidth supported by processor (max) | 19.2 GB/s |
| Memory clock speeds supported by processor | 800 MHz |
| Memory types supported by processor | DDR3-SDRAM |
| Number of QPI links | 2 |
| Physical Address Extension (PAE) | 40 bit |
| Physical Address Extension (PAE) | Yes |
| Processor code | SLBF9 |
| Processor codename | Nehalem EP |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor package size | 42.5 x 45 mm |
| Processor series | Intel Xeon 5500 Series |
| Processor socket | Socket B (LGA 1366) |
| Processor system type | DP |
| Processor threads | 4 |
| Stepping | D0 |
| Tcase | 76 °C |
| Thermal Monitoring Technologies | No |
| Conflict-Free processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR3-SDRAM |
| ECC | Yes |
| Memory slots | 12 |
| Maximum internal memory | 96 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 0 GB |
| HDD interface | Serial ATA |
| HDD size | 2.5" |
| RAID levels | 1, 5, 6 |
| Hot-swap | Yes |
Network
| Specification | Value |
|---|---|
| Network ready | Yes |
| LAN controller | Intel® 82575EB |
| Wake-on-LAN ready | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 7 |
| PS/2 ports quantity | 0 |
| Serial ports quantity | 1 |
| VGA (D-Sub) ports quantity | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 slots | 1 |
| PCI Express x8 slots | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
| Rack mounting | Yes |
Performance
| Specification | Value |
|---|---|
| Remote administration | Yes |
| Management platform | ServerView Suite |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows Server 2008 Windows Server 2003 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux Citrix XenServer VMware Infrastructure VMware vSphere 4.0 |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 2 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | Yes |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® Smart Cache | Yes |
| Intel® Turbo Boost Technology | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 40711 |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 1 |
| Power requirements | 100 - 127 V / 200 - 240 V |
| Power supply | 770 W |
| Power consumption (typical) | 466 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Relative humidity | 10 - 85% |
Certificates
| Specification | Value |
|---|---|
| Certification | GS CE CSAc/us ULc/us ICES-003 class A FCC Class A CB RoHS WEEE VCCI class A CNS 13438 class A |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 765 mm |
| Depth | 431 mm |
| Height | 43 mm |
| Weight | 18 kg |
Other features
| Specification | Value |
|---|---|
| Dimensions (WxDxH) | 431 x 765 x 43 mm |
| Fibre Channel | Yes |
| Supported data transfer rates | 10/100/1000 Mbit/s |
| Acoustic pressure emissions | 49 dB |
| Number of drive bays | 8 |
| Standard fans | 5 |
