Fujitsu RX1330 M2

Model RX1330 M2Part no. VFY:R1332SX070PTEAN 4058154045954

95 specifications

Overview

Brand: Fujitsu
Category: Server
Model: RX1330 M2
Part numbers: VFY:R1332SX070PT, VFY:R1332SC030IN S26361-F3909-L515, VFY:R1332SC040IN S26361-F3909-L515, VFY:R1332SC040IN?3YNBD, VFY:R1332SC040IN?5YNBD, VFY:R1332SX110CH +34 more
EAN / UPC: 4058154045954, 4057185545358, 4057185524513, 4057185524506 +14 more
Also known as: Fujitsu PRIMERGY RX1330 M2 server Rack (1U) Intel® Xeon® E3 v5 E3-1220V5 3 GHz 8 GB DDR4-SDRAM 450 W

95 specifications in 13 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 v5
Processor model	E3-1220V5
Processor frequency	3 GHz
Processor boost frequency	3.5 GHz
Processor cores	4
Processor cache	8 MB
Motherboard chipset	Intel® C236
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	80 W
Processor cache type	Smart Cache
System bus rate	8 GT/s
Bus type	QPI
ECC supported by processor	Yes
Embedded options available	No
Execute Disable Bit	Yes
Graphics & IMC lithography	14 nm
Idle States	Yes
Maximum internal memory supported by processor	64 GB
Maximum number of PCI Express lanes	16
Memory bandwidth supported by processor (max)	34.1 GB/s
Memory clock speeds supported by processor	1333,1600,1866,2133 MHz
Memory types supported by processor	DDR3L-SDRAM, DDR4-SDRAM
Memory voltage supported by processor	1.35 V
PCI Express configurations	1x16, 1x8+2x4, 2x8
Processor code	SR2LG
Processor codename	Skylake
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Xeon E3-1200 v5
Processor socket	LGA 1151 (Socket H4)
Processor threads	4
Scalability	1S
Stepping	R0
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes
Conflict-Free processor	Yes

Specification	Value
Number of displays supported (on-board graphics)	0

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
RS-232 ports	1
Serial ports quantity	1
VGA (D-Sub) ports quantity	1

Specification	Value
Chassis type	Rack (1U)

Specification	Value
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	2.0

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Enhanced Halt State	Yes
Intel Secure Key Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	No
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	88172

Specification	Value
Power supply	450 W

Specification	Value
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	10 - 85%

Specification	Value
Depth	572 mm
Height	42.8 mm
