Fujitsu PRIMERGY TX100 S1
Model PRIMERGY TX100 S1Part no. VFY:T1001SX320IN/B1EAN 4049699239472
95 specifications
- ProcessorIntel® Pentium®
- Memory2 GB
- Storage250 GB
- Weight12 kg
- Processor manufacturerIntel
- Networking featuresGigabit Ethernet
Overview
- Processor
- Intel® Pentium®
- Memory
- 2 GB
- Storage
- 250 GB
- Weight
- 12 kg
- Processor manufacturer
- Intel
- Networking features
- Gigabit Ethernet
- Brand
- Fujitsu
- Category
- Server
- Model
- PRIMERGY TX100 S1
- Part numbers
- VFY:T1001SX320IN/B1, VFY:T1001SX320IN/B2, VFY:T1001SX320IN/B3, VFY:T1001SX320IN/B5, VFY:T1001SX320IN/B7, VFY:T1001SX320IN/B4 +31 more
- EAN / UPC
- 4049699239472, 4049699239489, 4049699237966, 4049699239465 +19 more
- Also known as
- Fujitsu PRIMERGY TX100 S1 server 250 GB Tower Intel® Pentium® E5200 2.5 GHz 2 GB DDR2-SDRAM 300 W
Specifications
95 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Pentium® |
| Processor model | E5200 |
| Processor frequency | 2.5 GHz |
| Processor cores | 2 |
| Processor cache | 2 MB |
| Motherboard chipset | Intel® 3200 |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 65 W |
| Processor cache type | L2 |
| Bus type | FSB |
| CPU multiplier (bus/core ratio) | 12.5 |
| ECC supported by processor | No |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| FSB Parity | No |
| Idle States | Yes |
| Number of Processing Die Transistors | 228 M |
| Processing Die size | 82 mm² |
| Processor codename | Wolfdale |
| Processor front side bus | 800 MHz |
| Processor lithography | 45 nm |
| Processor operating modes | 64-bit |
| Processor package size | 37.5 x 37.5 mm |
| Processor series | Intel Pentium E5000 Series for Desktop |
| Processor socket | LGA 775 (Socket T) |
| Processor threads | 2 |
| Stepping | M0 |
| Tcase | 74.1 °C |
| Thermal Monitoring Technologies | Yes |
| Conflict-Free processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 2 GB |
| Internal memory type | DDR2-SDRAM |
| ECC | Yes |
| Memory clock speed | 800 MHz |
| Memory layout (slots x size) | 1 x 2 GB |
| Memory slots | 4 |
| Maximum internal memory | 8 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 250 GB |
| HDD interface | Serial ATA |
| HDD size | 3.5" |
| Hot-swap | No |
| Optical drive type | DVD-ROM |
Network
| Specification | Value |
|---|---|
| Networking features | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 10 |
| PS/2 ports quantity | 2 |
| Serial ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 slots | 1 |
| PCI Express x4 slots | 1 |
| PCI Express x8 slots | 1 |
| PCI slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows Server 2008/2003, Novell SUSE Linux Enterprise Server, Red Hat Enterprise Linux |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | No |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | No |
| Intel VT-x with Extended Page Tables (EPT) | No |
| Intel Virtualization Technology (VT-x) | No |
| Intel Virtualization Technology for Directed I/O (VT-d) | No |
| Intel® AES New Instructions (Intel® AES-NI) | No |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | No |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® Turbo Boost Technology | No |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 37212 |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | No |
| Number of power supply units | 1 |
| Power requirements | 100 - 127V/200 - 240V@50 - 60146Hz |
| Power supply | 300 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Certificates
| Specification | Value |
|---|---|
| Certification | GS, CE, CSAc/us, ULc/us, FCC Class A, CB, RoHS, WEEE |
Weight & dimensions
| Specification | Value |
|---|---|
| Weight | 12 kg |
Other features
| Specification | Value |
|---|---|
| CD read speed | 48x |
| Dimensions (WxDxH) | 203 x 386 x 390 mm |
| Power availability | 146 W |
| DVD interface type | SATA |
| DVD read speed | 16x |
