Fujitsu PRIMERGY BX630 S2
Model PRIMERGY BX630 S2Part no. VFY:B6302SX010DEEAN 4333643815479
45 specifications
- ProcessorAMD Opteron
- Memory4 GB
- Storage0 GB
- Weight6 kg
- Maximum storage capacity0.6 TB
- Supported network protocolsTCP/IP
Overview
- Processor
- AMD Opteron
- Memory
- 4 GB
- Storage
- 0 GB
- Weight
- 6 kg
- Maximum storage capacity
- 0.6 TB
- Supported network protocols
- TCP/IP
- Brand
- Fujitsu
- Category
- Server
- Model
- PRIMERGY BX630 S2
- Part number
- VFY:B6302SX010DE
- EAN / UPC
- 4333643815479
- Also known as
- Fujitsu PRIMERGY BX630 S2 server 0 GB Rack (1U) AMD Opteron 2.1 GHz 4 GB DDR2-SDRAM 388 W
Specifications
45 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Processor family | AMD Opteron |
| Processor frequency | 2.1 GHz |
| Processor cores | 4 |
| Processor cache | 2 MB |
| Number of processors installed | 1 |
| Processor cache type | L3 |
| Processor front side bus | 1000 MHz |
| Processor socket | Socket F (1207) |
Memory
| Specification | Value |
|---|---|
| Internal memory | 4 GB |
| Internal memory type | DDR2-SDRAM |
| ECC | Yes |
| Memory clock speed | 800 MHz |
| Memory layout (slots x size) | 2 x 2 GB |
| Memory slots | 8x DIMM |
| Maximum internal memory | 128 GB |
Storage
| Specification | Value |
|---|---|
| Maximum storage capacity | 0.6 TB |
| Total storage capacity | 0 GB |
| Number of HDDs installed | 0 |
| HDD size | 2.5" |
| Number of HDDs supported | 2 |
| RAID support | Yes |
| Hot-swap | Yes |
| Optical drive type | No |
Network
| Specification | Value |
|---|---|
| Supported network protocols | TCP/IP |
| Ethernet LAN | Yes |
| Networking features | Gigabyte Ethernet |
| Wake-on-LAN ready | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
| USB 2.0 ports quantity | 2 |
| PS/2 ports quantity | 0 |
| Serial ports quantity | 0 |
| VGA (D-Sub) ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows Server 2008 R2 Windows Server 2008 Windows Server 2003 R2 Novell SUSE Linux Enterprise Server Red Hat Enterprise Linux VMware Infrastructure |
| Bundled software | SV Installation Manager SV Operation Manager SV RAID Manager SV Update Management SV Power Management SV Agents |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | No |
| Number of power supply units | 1 |
| Power supply | 388 W |
Certificates
| Specification | Value |
|---|---|
| Compliance industry standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab |
| Certification | GS CE CSAc/us ULc/us FCC CB RoHS WEEE VCI C-Tick |
Sustainability
| Specification | Value |
|---|---|
| Sustainability certificates | ENERGY STAR |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 470 mm |
| Depth | 286 mm |
| Height | 43 mm |
| Weight | 6 kg |
