PRIMERGY LKN:T1335S0002PL server
0 GB Tower Intel Xeon E E-2378 2.6 GHz 16 GB DDR4-SDRAM 500 W
Model LKN:T1335S0002PL
71 specifications
- ProcessorIntel Xeon E
- Memory16 GB
- Storage0 GB
- Noise22 dB
- OSNo
- Weight26.4 kg
Overview
- Processor
- Intel Xeon E
- Memory
- 16 GB
- Storage
- 0 GB
- Noise
- 22 dB
- OS
- No
- Weight
- 26.4 kg
- Brand
- Fujitsu
- Category
- Server
- Model
- LKN:T1335S0002PL
- Part number
- LKN:T1335S0002PL
- Also known as
- Fujitsu PRIMERGY LKN:T1335S0002PL server 0 GB Tower Intel Xeon E E-2378 2.6 GHz 16 GB DDR4-SDRAM 500 W
Specifications
71 specifications in 16 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2378 |
| Processor frequency | 2.6 GHz |
| Processor boost frequency | 4.8 GHz |
| Processor cores | 8 |
| Processor cache | 16 MB |
| Motherboard chipset | Intel C256 |
| Number of processors installed | 1 |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Maximum number of SMP processors | 1 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | Yes |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4x DIMM |
| Maximum internal memory | 128 GB |
Storage
| Specification | Value |
|---|---|
| Maximum storage capacity | 0 TB |
| Total storage capacity | 0 GB |
| Number of HDDs supported | 8 |
| Supported HDD sizes | 3.5" |
| RAID support | Yes |
| Hot-Plug support | Yes |
| Optical drive type | DVD-RW |
Network
| Specification | Value |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Intel I210 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 4 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Total number of SATA connectors | 7 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 (Gen 3.x) slots | 2 |
| PCI Express x8 (Gen 4.x) slots | 2 |
| PCI slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black |
| Rack mounting | Yes |
| Redundant fans support | Yes |
Performance
| Specification | Value |
|---|---|
| Noise level | 22 dB |
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Windows Server 2022 Datacenter, Windows Server 2022 Standard, Windows Server 2022 Essentials, Windows Server 2019 Datacenter, Windows Server 2019 Standard, Windows Server 2019 Essentials, VMware vSphere 7.0, Red Hat Enterprise Linux 8, Univention Corporate Server 4 |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Power supply | 500 W |
| Power supply input voltage | 100 - 240 V |
| Power supply input frequency | 50 / 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 45 °C |
| Operating relative humidity (H-H) | 10 - 85% |
Certificates
| Specification | Value |
|---|---|
| Certification | CB, GS, CE, NRTLc/us, FCC, ICES-003, NMB-003, VCCI, JIS 61000-3-2, EAC, KC, CCC, RCM, BSMI |
Sustainability
| Specification | Value |
|---|---|
| Sustainability compliance | Yes |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 177.2 mm |
| Depth | 521.7 mm |
| Height | 456.2 mm |
| Weight | 26.4 kg |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS, WEEE |
