VIKING-R1-4TB server
4.25 TB Intel® Xeon® D D-1518 2.2 GHz 8 GB DDR4-SDRAM 200 W Windows 10 Pro
Model VIKING-R1-4TBEAN 5704174229414
49 specifications
- ProcessorIntel® Xeon® D
- Memory8 GB
- Storage4.25 TB
- OSWindows 10 Pro
- Weight5.5 kg
- ColourBlack
Overview
- Processor
- Intel® Xeon® D
- Memory
- 8 GB
- Storage
- 4.25 TB
- OS
- Windows 10 Pro
- Weight
- 5.5 kg
- Colour
- Black
- Brand
- Ernitec
- Category
- Server
- Model
- VIKING-R1-4TB
- Part number
- VIKING-R1-4TB
- EAN / UPC
- 5704174229414, 5706998615862
- Also known as
- Ernitec VIKING-R1-4TB server 4.25 TB Intel® Xeon® D D-1518 2.2 GHz 8 GB DDR4-SDRAM 200 W Windows 10 Pro
Specifications
49 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® D |
| Processor model | D-1518 |
| Processor frequency | 2.2 GHz |
| Embedded options available | Yes |
| Execute Disable Bit | Yes |
| Idle States | Yes |
| Conflict-Free processor | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR4-SDRAM |
| ECC | No |
| Memory clock speed | 2400 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 4.25 TB |
| Number of HDDs installed | 1 |
| HDD capacity | 4 TB |
| HDD interface | Serial ATA |
| SSD capacity | 250 GB |
| SSD interface | M.2 |
| Optical drive type | No |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| LAN controller | Intel I210, Intel® I350-AM4 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 7 |
| USB 2.0 ports quantity | 5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| VGA (D-Sub) ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Product colour | Black |
| Rack mounting | Yes |
| Redundant fans support | Yes |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 10 Pro |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Enhanced Halt State | Yes |
| Intel Secure Key Technology version | 1.00 |
| Intel TSX-NI | Yes |
| Intel TSX-NI version | 1.00 |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Power
| Specification | Value |
|---|---|
| Power supply | 200 W |
| Power supply input frequency | 50/60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 8 - 90% |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 437 mm |
| Depth | 249 mm |
| Height | 43 mm |
| Weight | 5.5 kg |
Other features
| Specification | Value |
|---|---|
| Bandwidth | 0.12 Gbit/s |
