-BX-I3-8-R2 server
500 GB Rack Intel® Core™ i3 4.3 GHz 8 GB DDR5-SDRAM 200 W
Model SERVER-BX-I3-8-R2EAN 5715063109809
56 specifications
- ProcessorIntel® Core™ i3
- Memory8 GB
- Storage500 GB
- Type1U
- Weight5 kg
- Processor manufacturerIntel
Overview
- Processor
- Intel® Core™ i3
- Memory
- 8 GB
- Storage
- 500 GB
- Type
- 1U
- Weight
- 5 kg
- Processor manufacturer
- Intel
- Brand
- Ernitec
- Category
- Server
- Model
- SERVER-BX-I3-8-R2
- Part number
- SERVER-BX-I3-8-R2
- EAN / UPC
- 5715063109809
- Also known as
- Ernitec -BX-I3-8-R2 server 500 GB Rack Intel® Core™ i3 4.3 GHz 8 GB DDR5-SDRAM 200 W
Specifications
56 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Core™ i3 |
| Processor frequency | 4.3 GHz |
| Performance-core base frequency | 3.3 GHz |
| Performance-core Max Turbo Frequency | 4.3 GHz |
| Performance cores | 4 |
| Processor cores | 4 |
| Processor cache | 12 MB |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 60 W |
| Processor socket | LGA 1700 |
| Processor threads | 8 |
| Intelligent Platform Management Interface (IPMI) support | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 8 GB |
| Internal memory type | DDR5-SDRAM |
| Buffered memory type | Unregistered (unbuffered) |
| Memory clock speed | 4400 MHz |
| Memory layout (slots x size) | 1 x 8 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 500 GB |
| Number of HDDs supported | 2 |
| Supported HDD sizes | 2.5" |
| SSD capacity | 500 GB |
| NVMe | Yes |
| RAID levels | 0 |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | Intel UHD Graphics 730 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet |
| LAN controller | Intel I225-LM |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack |
Performance
| Specification | Value |
|---|---|
| BIOS type | UEFI |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Compatible operating systems | Windows 10/11, Windows Server 2022 |
Power
| Specification | Value |
|---|---|
| Number of power supply units | 1 |
| Power supply | 200 W |
| Number of main power supplies | 1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 437 mm |
| Depth | 249 mm |
| Height | 43 mm |
| Weight | 5 kg |
| Package width | 660 mm |
| Package depth | 470 mm |
| Package height | 160 mm |
| Package weight | 7 kg |
Technical details
| Specification | Value |
|---|---|
| Number of 3.5" bays | 0 |
| Number of storage drives supported | 2 |
| 2.5" HDD support | 2 |
| 3.5" HDD support | 0 |
Other features
| Specification | Value |
|---|---|
| Form factor | 1U |
| Number of DIMM slots | 4 |
| Number of SATA connectors | 4 |
| Number of drive bays | 2 |
| RAID controller type | Software RAID |
| Warranty period | 5 year(s) |
