SC-E54-A4 server Cube E-2456
16 GB DDR5-SDRAM Windows 11 Pro
Model SC-E54-A4EAN 5715328141827
59 specifications
- ProcessorE-2456
- Memory16 GB
- Storage500 GB
- OSWindows 11 Pro
- Weight5 kg
- ColourBlack
Overview
- Processor
- E-2456
- Memory
- 16 GB
- Storage
- 500 GB
- OS
- Windows 11 Pro
- Weight
- 5 kg
- Colour
- Black
- Brand
- Ernitec
- Category
- Server
- Model
- SC-E54-A4
- Part number
- SC-E54-A4
- EAN / UPC
- 5715328141827
- Also known as
- Ernitec SC-E54-A4 server Cube E-2456 16 GB DDR5-SDRAM Windows 11 Pro
Specifications
59 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor model | E-2456 |
| Performance-core base frequency | 3.3 GHz |
| Performance-core Max Turbo Frequency | 5.1 GHz |
| Performance cores | 6 |
| Processor cores | 6 |
| Processor threads | 12 |
| Cache internal | 18 MB |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR5-SDRAM |
| Buffered memory type | Unregistered (unbuffered) |
| ECC | Yes |
| Memory layout (slots x size) | 2 x 8 GB |
| Memory data transfer rate | 4400 MT/s |
| Maximum internal memory | 64 GB |
Storage
| Specification | Value |
|---|---|
| HDD capacity | 500 GB |
| Number of HDDs supported | 4 |
| Supported HDD sizes | 2.5" |
| Number of SSDs installed | 1 |
| SSD capacity | 500 GB |
| SSD size | 2.5" |
| Number of SSDs supported | 2 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card memory | 4 GB |
| On-board graphics card | Yes |
| On-board graphics card model | Aspeed AST2600 |
| Number of displays supported (on-board graphics) | 1 |
| On-board graphics card 4K support | Yes |
Network
| Specification | Value |
|---|---|
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Intel® I210-AT |
| Number of LAN controllers | 2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Mini DisplayPorts quantity | 4 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x16 (Gen 4.x) slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Cube |
| Product colour | Black |
| Cooling type | Active |
| Rack mounting | No |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
| Trusted Platform Module (TPM) version | 2.0 |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows 11 Pro |
| Operating system language | Multilingual |
Power
| Specification | Value |
|---|---|
| Number of main power supplies | 1 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 290 mm |
| Depth | 330 mm |
| Height | 390 mm |
| Weight | 5 kg |
| Package width | 290 mm |
| Package depth | 330 mm |
| Package height | 390 mm |
| Package weight | 6 kg |
Technical details
| Specification | Value |
|---|---|
| Number of 3.5" bays | 4 |
Other features
| Specification | Value |
|---|---|
| Integrated BMC with IPMI | Yes |
| Integrated LAN | Yes |
| RAID controller type | Software |
| Warranty period | 3 year(s) |
