T360 + WS Standard 2025
Model T360 + WS Standard 2025Part no. F81V0+634-CVFM
75 specifications
- ProcessorIntel Xeon 6
- Memory32 GB
- Storage480 GB
- OSWindows Server 2025 Standard
- ColourBlack
- Processor manufacturerIntel
Overview
- Processor
- Intel Xeon 6
- Memory
- 32 GB
- Storage
- 480 GB
- OS
- Windows Server 2025 Standard
- Colour
- Black
- Processor manufacturer
- Intel
- Brand
- Dell
- Category
- Server
- Model
- T360 + WS Standard 2025
- Part numbers
- F81V0+634-CVFM, V3J7K+634-CVFM, 64TG7+634-CVFM, 6YVRW+634-CVFM
- Also known as
- DELL PowerEdge T360 + WS Standard 2025 server 480 GB Tower (4.5U) Intel Xeon 6 6333P 3.1 GHz 32 GB DDR5-SDRAM 700 W Windows Server 2025 Standard
Specifications
75 specifications in 15 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon 6 |
| Processor model | 6333P |
| Processor frequency | 3.1 GHz |
| Processor boost frequency | 5.2 GHz |
| Performance cores | 6 |
| Processor cache | 18 MB |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 65 W |
| System bus rate | 16 GT/s |
| Memory clock speeds supported by processor | 4800 MHz |
| Memory types supported by processor | DDR5-SDRAM |
| Processor threads | 12 |
Memory
| Specification | Value |
|---|---|
| Internal memory | 32 GB |
| Internal memory type | DDR5-SDRAM |
| Buffered memory type | Unregistered (unbuffered) |
| ECC | Yes |
| Memory layout (slots x size) | 1 x 32 GB |
| Memory slots | 4x DIMM |
| Memory data transfer rate | 5600 MT/s |
| Maximum internal memory | 128 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 480 GB |
| SSD capacity | 480 GB |
| SSD interface | SATA III |
| SSD size | 2.5" |
| Supported SSD sizes | 3.5" |
| Number of SSDs supported | 8 |
| RAID support | No |
| Supported RAID controllers | PERC H755 Adapter FH |
| Hot-Plug support | Yes |
| Drive writes per day (DWPD) | 1 |
| Optical drive type | No |
| Storage drive adapter included | Yes |
| Storage drive adapter type | 2.5" - 3.5" |
Network
| Specification | Value |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Broadcom 5720 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Power cables quantity | 2 |
| Serial ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x4 slots | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower (4.5U) |
| Product colour | Black |
Performance
| Specification | Value |
|---|---|
| Remote administration | iDRAC9, Enterprise 16G |
Software
| Specification | Value |
|---|---|
| Operating system installed | Windows Server 2025 Standard |
| Compatible operating systems | Canonical Ubuntu Server LTS Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | No |
| Power supply | 700 W |
| Number of main power supplies | 1 |
| Power supply input voltage | 200 - 240 V |
| Power cable length | 2 m |
| Power cable connector 1 | C13 coupler |
| Power cable connector 2 | C14 coupler |
| Power cable current | 10 A |
Operational conditions
| Specification | Value |
|---|---|
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 2048 m |
| Non-operating altitude | 0 - 12000 m |
Certificates
| Specification | Value |
|---|---|
| 80 PLUS certification | 80 PLUS Titanium |
Carbon footprint
| Specification | Value |
|---|---|
| Carbon emissions, end-of-life (kg of CO2e) | 28.18 |
| Carbon emissions, energy usage (kg of CO2e) | 929.94 |
| Carbon emissions, logistics (kg of CO2e) | 154.99 |
| Carbon emissions, manufacturing (kg of CO2e) | 295.89 |
| PAIA version | 1.4.0, 2024 |
| Total carbon emissions, standard deviation (kg of CO2e) | 1213 |
| Total carbon footprint (kg of CO2e) | 1409 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 175 mm |
| Depth | 581.1 mm |
Other features
| Specification | Value |
|---|---|
| Bytes per sector | 512e |
| Data transfer rate | 6 Gbit/s |
| Target workload | Read Intensive (RI) |
