PowerEdge T350 server
2 TB Tower Intel Xeon E E-2314 2.8 GHz 16 GB DDR4-SDRAM 600 W
Model T350Part no. T350SNSFY23Q1MXEAN 5397184677452
76 specifications
- ProcessorIntel Xeon E
- Memory16 GB
- Storage2 TB
- OSNo
- Weight25.3 kg
- ColourBlack
Overview
- Processor
- Intel Xeon E
- Memory
- 16 GB
- Storage
- 2 TB
- OS
- No
- Weight
- 25.3 kg
- Colour
- Black
- Brand
- Dell
- Category
- Server
- Model
- T350
- Part numbers
- T350SNSFY23Q1MX, 210-BCNW-JJ21, T350SNSFY23Q1MXV2, G0N7D, 742K8, VNXJC +34 more
- EAN / UPC
- 5397184677452, 884116419501, 884116419617, 5901165753266 +15 more
- Also known as
- DELL PowerEdge T350 server 2 TB Tower Intel Xeon E E-2314 2.8 GHz 16 GB DDR4-SDRAM 600 W
Specifications
76 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel Xeon E |
| Processor model | E-2314 |
| Processor frequency | 2.8 GHz |
| Processor boost frequency | 4.5 GHz |
| Processor cores | 4 |
| Processor cache | 8 MB |
| Number of processors installed | 1 |
| Execute Disable Bit | Yes |
| Idle States | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Buffered memory type | Unregistered (unbuffered) |
| ECC | Yes |
| Memory clock speed | 3200 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Memory slots | 4x DIMM |
| Maximum internal memory | 64 GB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 2 TB |
| Number of HDDs installed | 1 |
| HDD capacity | 2 TB |
| HDD interface | SATA |
| HDD speed | 7200 RPM |
| HDD size | 3.5" |
| RAID support | No |
| Supported RAID controllers | PERC H355 |
| Hot-Plug support | Yes |
| Optical drive type | No |
Network
| Specification | Value |
|---|---|
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| USB 2.0 ports quantity | 5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Parallel ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black |
| Bezel | Yes |
Performance
| Specification | Value |
|---|---|
| Remote administration | iDRAC9 Basic 15G |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Canonical Ubuntu Server LTS Citrix Hypervisor Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 1 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Software Guard Extensions (Intel SGX) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Power supply | 600 W |
| Number of redundant power supplies supported | 2 |
| Number of redundant power supplies installed | 1 |
| Power supply input voltage | 100 - 240 V |
| Power cable length | 2 m |
| Power cable connector 1 | C13 coupler |
| Power cable connector 2 | C14 coupler |
| Power cable current | 10 A |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 65 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating altitude | 0 - 3048 m |
| Non-operating altitude | 0 - 12000 m |
Carbon footprint
| Specification | Value |
|---|---|
| Carbon emissions, end-of-life (kg of CO2e) | 31 |
| Carbon emissions, energy usage (kg of CO2e) | 1630 |
| Carbon emissions, logistics (kg of CO2e) | 198 |
| Carbon emissions, manufacturing (kg of CO2e) | 453 |
| PAIA version | 1.3.2, 2022 |
| Total carbon emissions, standard deviation (kg of CO2e) | 999 |
| Total carbon emissions, w/o use phase (kg of CO2e) | 682 |
| Total carbon footprint (kg of CO2e) | 2310 |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 175 mm |
| Depth | 581.1 mm |
| Height | 369.5 mm |
| Weight | 25.3 kg |
