Dell T330+Windows Server 2016 Essentials

Model T330+Windows Server 2016 EssentialsPart no. T330-2844?ESSENTIALKIT

96 specifications

Overview

Brand: Dell
Category: Server
Model: T330+Windows Server 2016 Essentials
Part number: T330-2844?ESSENTIALKIT
Also known as: DELL PowerEdge T330+Windows 2016 Essentials server 1 TB Tower (5U) Intel® Xeon® E3 v6 E3-1220 v6 3 GHz 8 GB DDR4-SDRAM 495 W Windows Server 2016 Essentials

96 specifications in 13 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 v6
Processor model	E3-1220 v6
Processor frequency	3 GHz
Processor boost frequency	3.5 GHz
Processor cores	4
Processor cache	8 MB
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	72 W
Processor cache type	Smart Cache
System bus rate	8 GT/s
Bus type	DMI3
ECC supported by processor	Yes
Embedded options available	No
Execute Disable Bit	Yes
Idle States	Yes
Maximum internal memory supported by processor	64 GB
Maximum number of PCI Express lanes	16
Memory bandwidth supported by processor (max)	37.5 GB/s
Memory clock speeds supported by processor	1866,2133 MHz
Memory types supported by processor	DDR3L, DDR4-SDRAM
PCI Express configurations	1x16, 1x8+2x4, 2x8
Processor codename	Kaby Lake
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor socket	LGA 1151 (Socket H4)
Processor threads	4
Scalability	1S
Supported instruction sets	AVX 2.0, SSE4.1, SSE4.2
Thermal Monitoring Technologies	Yes
Conflict-Free processor	Yes

Specification	Value
Total storage capacity	1 TB
Number of HDDs installed	1
HDD capacity	1 TB
HDD interface	Serial ATA
HDD speed	7200 RPM
HDD size	3.5"
Number of HDDs supported	8
Supported HDD sizes	2.5,3.5"
RAID support	Yes
Hot-Plug support	Yes
Optical drive type	DVD±RW
Supported storage drive interfaces	SAS, Serial ATA

Specification	Value
On-board graphics card	Yes
On-board graphics card model	Matrox G200

Specification	Value
Ethernet LAN (RJ-45) ports	2
USB 2.0 ports quantity	5
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	3
Serial ports quantity	1
VGA (D-Sub) ports quantity	1

Specification	Value
Chassis type	Tower (5U)
Rack mounting	Yes

Specification	Value
Operating system installed	Windows Server 2016 Essentials

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Enhanced Halt State	Yes
Intel Secure Key Technology version	1.00
Intel Software Guard Extensions (Intel SGX)	Yes
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® InTru™ 3D Technology	No
Intel® OS Guard	Yes
Intel® Quick Sync Video Technology	No
Intel® Secure Key	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	97470

Specification	Value
Power supply	495 W
Number of main power supplies	1

Specification	Value
Number of 3.5" bays	8
