Dell PowerEdge R740 server

300 GB Rack (2U) Intel Xeon Silver 4116 2.1 GHz 16 GB DDR4-SDRAM 495 W

Model R740Part no. R740-4120EAN 5397184012451

90 specifications

Overview

Brand: Dell
Category: Server
Model: R740
Part numbers: R740-4120, PER740PL11, R740-2451, R740-2444, R740-2437, 49VPW +34 more
EAN / UPC: 5397184012451, 5397184012444, 7330381328046, 5397184012437 +35 more
Also known as: DELL PowerEdge R740 server 300 GB Rack (2U) Intel Xeon Silver 4116 2.1 GHz 16 GB DDR4-SDRAM 495 W

90 specifications in 13 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel Xeon Silver
Processor generation	1st Generation Intel® Xeon® Scalable
Processor model	4116
Processor frequency	2.1 GHz
Processor boost frequency	3 GHz
Processor cores	12
Processor cache	16.5 MB
Memory channels supported by processor	Hexa
Number of processors installed	2
Thermal Design Power (TDP)	85 W
Processor cache type	L3
Compatible processor series	Intel® Xeon®
ECC supported by processor	Yes
Embedded options available	Yes
Execute Disable Bit	Yes
Maximum internal memory supported by processor	768 GB
Maximum number of PCI Express lanes	48
Memory clock speeds supported by processor	2400 MHz
Memory types supported by processor	DDR4-SDRAM
Processor code	SR3HQ
Processor codename	Skylake
Processor lithography	14 nm
Processor operating modes	64-bit
Processor package size	76.0 x 56.5 mm
Processor socket	LGA 3647 (Socket P)
Processor threads	24
Scalability	2S
Stepping	M0
Supported instruction sets	AVX, AVX 2.0, AVX-512, SSE4.2
Tcase	76 °C
Conflict-Free processor	Yes

Specification	Value
Maximum storage capacity	80 TB
Total storage capacity	300 GB
Number of HDDs installed	1
HDD capacity	300 GB
HDD interface	Serial Attached SCSI (SAS)
HDD speed	10000 RPM
HDD size	2.5"
Number of HDDs supported	8
Supported HDD sizes	2.5"
RAID support	Yes
Hot-Plug support	Yes
Hot-swap	Yes
Optical drive type	DVD±RW
Supported storage drive interfaces	Serial ATA, Serial Attached SCSI

Specification	Value
Ethernet LAN (RJ-45) ports	4
USB 2.0 ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Serial ports quantity	1
VGA (D-Sub) ports quantity	2

Specification	Value
PCI Express x8 (Gen 3.x) slots	4
PCI Express slots version	3.0

Specification	Value
Remote administration	iDRAC9 Enterprise
Trusted Platform Module (TPM)	Yes
Trusted Platform Module (TPM) version	1.2

Specification	Value
Compatible operating systems	Canonical Ubuntu LTS Citrix XenServer Microsoft Windows Server with Hyper-V Red Hat Enterprise Linux SUSE Linux Enterprise Server VMware ESXi

Specification	Value
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel TSX-NI	Yes
Intel TSX-NI version	1.00
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Turbo Boost Technology	2.0
Processor ARK ID	120481

Specification	Value
Redundant power supply (RPS) support	Yes
Power supply	495 W

Specification	Value
Conflict-Free	Yes
Dell E-Value Code	PER7403
