PowerEdge MX840c server
600 GB Intel® Xeon® Platinum 8280L 2.7 GHz 16 GB
Model MX840cPart no. PE_MX840C_12863
47 specifications
- ProcessorIntel® Xeon® Platinum
- Memory16 GB
- Storage600 GB
- Processor manufacturerIntel
- On-board graphics cardNo
- PCI Express slots version3.0
Overview
- Processor
- Intel® Xeon® Platinum
- Memory
- 16 GB
- Storage
- 600 GB
- Processor manufacturer
- Intel
- On-board graphics card
- No
- PCI Express slots version
- 3.0
- Brand
- Dell
- Category
- Server
- Model
- MX840c
- Part numbers
- PE_MX840C_12863, EMEA_MX840C_VI_VP
- Also known as
- DELL PowerEdge MX840c server 600 GB Intel® Xeon® Platinum 8280L 2.7 GHz 16 GB
Specifications
47 specifications in 6 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® Platinum |
| Processor generation | 2nd Generation Intel® Xeon® Scalable |
| Processor model | 8280L |
| Processor frequency | 2.7 GHz |
| Processor boost frequency | 4 GHz |
| Processor cores | 28 |
| Processor cache | 38.5 MB |
| Number of processors installed | 2 |
| Thermal Design Power (TDP) | 205 W |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| Maximum internal memory supported by processor | 4.6 TB |
| Maximum number of PCI Express lanes | 48 |
| Memory clock speeds supported by processor | 2933 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Processor codename | Cascade Lake |
| Processor lithography | 14 nm |
| Processor operating modes | 64-bit |
| Processor package size | 76.0 x 56.5 mm |
| Processor socket | LGA 3647 (Socket P) |
| Processor threads | 56 |
| Scalability | S8S |
| Supported instruction sets | AVX-512 |
| Tcase | 84 °C |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Memory clock speed | 2666 MHz |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 600 GB |
| Number of HDDs installed | 1 |
| HDD interface | Serial Attached SCSI (SAS) |
| HDD size | 2.5" |
| RAID support | Yes |
| Optical drive type | No |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card | No |
| On-board graphics card model | Not available |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 3.0 |
Processor special features
| Specification | Value |
|---|---|
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel TSX-NI | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® Turbo Boost Technology | 2.0 |
| Processor ARK ID | 192472 |
