SERVERline R54401a
Model SERVERline R54401aPart no. 850735EAN 4250749712542
56 specifications
- ProcessorAMD EPYC
- Memory256 GB
- Storage3.84 TB
- GraphicsNVIDIA RTX PRO 6000 Blackwell
- ColourBlack, Silver
- Processor manufacturerAMD
Overview
- Processor
- AMD EPYC
- Memory
- 256 GB
- Storage
- 3.84 TB
- Graphics
- NVIDIA RTX PRO 6000 Blackwell
- Colour
- Black, Silver
- Processor manufacturer
- AMD
- Brand
- bluechip
- Category
- Server
- Model
- SERVERline R54401a
- Part number
- 850735
- EAN / UPC
- 4250749712542
- Also known as
- bluechip SERVERline R54401a server 3.84 TB Rack (4U) AMD EPYC 9254 2.9 GHz 256 GB DDR5-SDRAM 3200 W
Specifications
56 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | AMD |
| Processor family | AMD EPYC |
| Processor generation | AMD EPYC™ 9004 Series |
| Processor model | 9254 |
| Processor frequency | 2.9 GHz |
| Processor boost frequency | 4.15 GHz |
| Processor cores | 24 |
| Processor cache | 128 MB |
| Number of processors installed | 2 |
| Thermal Design Power (TDP) | 200 W |
| Processor socket | Socket SP5 |
| Processor threads | 48 |
| Intelligent Platform Management Interface (IPMI) support | Yes |
Memory
| Specification | Value |
|---|---|
| Internal memory | 256 GB |
| Internal memory type | DDR5-SDRAM |
| ECC | Yes |
| Memory clock speed | 4800 MHz |
| Memory layout (slots x size) | 4 x 64 GB |
| Memory slots | 24x DIMM |
| Maximum internal memory | 3 TB |
Storage
| Specification | Value |
|---|---|
| Total storage capacity | 3.84 TB |
| Number of SSDs installed | 2 |
| SSD capacity | 1.92 TB |
| NVMe | Yes |
| SSD size | 2.5" |
| RAID support | No |
| Hot-swap | Yes |
| Internal drive bays | 8 |
Graphics
| Specification | Value |
|---|---|
| Discrete graphics card | Yes |
| Discrete graphics card model | NVIDIA RTX PRO 6000 Blackwell |
| Discrete graphics memory type | GDDR7 |
| Number of discrete graphics cards | 4 |
| On-board graphics card | Yes |
| On-board graphics card family | Aspeed |
| On-board graphics card model | Aspeed AST2600 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet, 25 Gigabit Ethernet |
| LAN controller | Intel I710-AT2, Broadcom BCM57414 |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 2 |
| SFP/SFP+ slots quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| Mini DisplayPorts quantity | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x16 (Gen 5.x) slots | 8 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (4U) |
| Product colour | Black, Silver |
Performance
| Specification | Value |
|---|---|
| Trusted Platform Module (TPM) | Yes |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Power supply | 3200 W |
| Number of redundant power supplies installed | 2 |
Certificates
| Specification | Value |
|---|---|
| 80 PLUS certification | 80 PLUS Titanium |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 439 mm |
| Depth | 800 mm |
| Height | 175 mm |
Technical details
| Specification | Value |
|---|---|
| Compliance certificates | RoHS |
| Supported storage drives form factor (internal) | 2.5" |
Other features
| Specification | Value |
|---|---|
| Motherboard manufacturer | ASUS K15PG-D24 |
