Acer AT110 F2

Model AT110 F2Part no. ST.R7G11.00ZEAN 4712196354459

111 specifications

Overview

Brand: Acer
Category: Server
Model: AT110 F2
Part numbers: ST.R7G11.00Z, TT.R7G00.001, TT.R7G00.003, TT.R7G00.004, ST.R7G11.00C
EAN / UPC: 4712196354459, 884483898688, 8844838986882, 884483898701 +3 more
Also known as: Acer Altos AT110 F2 server 500 GB Tower Intel® Core™ i3 i3-2100 3.1 GHz 2 GB DDR3-SDRAM 450 W

111 specifications in 15 groups

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Core™ i3
Processor generation	2nd gen Intel® Core™ i3
Processor model	i3-2100
Processor frequency	3.1 GHz
Processor cores	2
Processor cache	3 MB
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	35, 65
Processor cache type	Smart Cache
System bus rate	5 GT/s
Bus type	DMI
CPU multiplier (bus/core ratio)	31
ECC supported by processor	No
Embedded options available	No
Execute Disable Bit	Yes
FSB Parity	No
Idle States	Yes
Maximum internal memory supported by processor	32 GB
Maximum number of PCI Express lanes	16
Memory bandwidth supported by processor (max)	21 GB/s
Memory clock speeds supported by processor	1066,1333 MHz
Memory types supported by processor	DDR3-SDRAM
Processor codename	Sandy Bridge
Processor lithography	32 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Core i3-2100 Desktop Series
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Stepping	Q0
Supported instruction sets	AVX
Tcase	69.1 °C
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Specification	Value
On-board graphics card	Yes
On-board graphics card family	Intel® HD Graphics
On-board graphics card model	Intel® HD Graphics 2000
Number of displays supported (on-board graphics)	2
On-board graphics card ID	0x102
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1100 MHz

Specification	Value
Chassis type	Tower

Specification	Value
Compatible operating systems	Windows Server 2003/2008/2008 R2 Red Hat Enterprise Linux 5.4/Novell SUSE/Linux Enterprise Server 11

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	No
Intel Dual Display Capable Technology	Yes
Intel Enhanced Halt State	Yes
Intel FDI Technology	Yes
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Identity Protection Technology version	1.00
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	No
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	No
Intel® AES New Instructions (Intel® AES-NI)	No
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	Yes
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	Yes
Intel® Insider™	Yes
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	Yes
Intel® Turbo Boost Technology	No
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	53422

Specification	Value
Power supply	450 W

Specification	Value
Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	30 - 80%
Storage relative humidity (H-H)	5 - 95%

Specification	Value
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Certification	CE/FCC

Specification	Value
Sustainability certificates	ENERGY STAR
