Acer 2000ht-AW170htq F1
Model 2000ht-AW170htq F1Part no. TG.R7800.011EAN 8844838953358
137 specifications
- ProcessorIntel® Xeon® 5000 Sequence
- Memory16 GB
- Storage0 GB
- OSNo
- Weight30.9 kg
- Processor manufacturerIntel
Overview
- Processor
- Intel® Xeon® 5000 Sequence
- Memory
- 16 GB
- Storage
- 0 GB
- OS
- No
- Weight
- 30.9 kg
- Processor manufacturer
- Intel
- Brand
- Acer
- Category
- Server
- Model
- 2000ht-AW170htq F1
- Part numbers
- TG.R7800.011, TG.R7800.009, TG.R7800.014, TG.R7800.015, TG.R7800.008
- EAN / UPC
- 8844838953358, 884483895311, 8844838953112, 884483897032 +6 more
- Also known as
- Acer AW 2000ht-AW170htq F1 server 0 GB Rack (2U) Intel® Xeon® 5000 Sequence X5650 2.66 GHz 16 GB DDR3-SDRAM 1400 W
Specifications
137 specifications in 16 groups
Processor
| Specification | Value |
|---|---|
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® 5000 Sequence |
| Processor model | X5650 |
| Processor frequency | 2.66 GHz |
| Processor boost frequency | 3.06 GHz |
| Processor cores | 6 |
| Processor cache | 12 MB |
| Memory channels supported by processor | Triple |
| Number of processors installed | 2 |
| Thermal Design Power (TDP) | 95 W |
| Processor cache type | Smart Cache |
| System bus rate | 6.4 GT/s |
| Bus type | QPI |
| CPU multiplier (bus/core ratio) | 20 |
| Compatible processor series | Intel® Xeon® |
| ECC supported by processor | Yes |
| Embedded options available | No |
| Execute Disable Bit | Yes |
| FSB Parity | No |
| Idle States | Yes |
| Maximum internal memory supported by processor | 288 GB |
| Maximum number of SMP processors | 4 |
| Memory bandwidth supported by processor (max) | 32 GB/s |
| Memory clock speeds supported by processor | 800,1066,1333 MHz |
| Memory types supported by processor | DDR3-SDRAM |
| Number of QPI links | 2 |
| Physical Address Extension (PAE) | 40 bit |
| Processor code | SLBV3 |
| Processor codename | Westmere EP |
| Processor lithography | 32 nm |
| Processor operating modes | 64-bit |
| Processor package size | 42.5 X 45 mm |
| Processor series | Intel Xeon 5600 Series |
| Processor socket | Socket B (LGA 1366) |
| Processor system type | DP |
| Processor threads | 12 |
| Stepping | B1 |
| Supported instruction sets | SSE4.2 |
| Tcase | 81.3 °C |
| Thermal Monitoring Technologies | No |
| Conflict-Free processor | No |
Memory
| Specification | Value |
|---|---|
| Internal memory | 16 GB |
| Internal memory type | DDR3-SDRAM |
| ECC | Yes |
| Memory clock speed | 1333 MHz |
| Memory layout (slots x size) | 4 x 4 GB |
| Memory slots | 24 |
| Maximum internal memory | 384 GB |
Storage
| Specification | Value |
|---|---|
| Maximum storage capacity | 24 TB |
| Total storage capacity | 0 GB |
| Number of HDDs installed | 0 |
| HDD interface | Serial ATA |
| HDD size | 3.5" |
| Number of HDDs supported | 12 |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Hot-swap | Yes |
| Optical drive type | No |
Graphics
| Specification | Value |
|---|---|
| Maximum graphics card memory | 16 MB |
Network
| Specification | Value |
|---|---|
| Network ready | Yes |
| Wi-Fi | No |
| Bluetooth | No |
| Cabling technology | 10/100/1000Base-T(X) |
| Ethernet LAN | Yes |
| LAN controller | Intel® 82574L |
| Networking features | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 6 |
| USB 2.0 ports quantity | 4 |
| DisplayPorts quantity | 0 |
| FireWire 800 | No |
| Firewire (IEEE 1394) ports | 0 |
| Mini DisplayPorts quantity | 0 |
| PS/2 ports quantity | 0 |
| Parallel ports quantity | 0 |
| Serial ports quantity | 2 |
| VGA (D-Sub) ports quantity | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 slots | 0 |
| PCI Express x4 slots | 0 |
| PCI Express x8 slots | 4 |
| PCI Express x16 slots | 2 |
| AGP x4 slots | 0 |
| AGP x8 slots | 0 |
| PCI slots | 0 |
| PCI-X slots | 0 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (2U) |
Software
| Specification | Value |
|---|---|
| Operating system installed | No |
| Compatible operating systems | Windows Server 2008, Windows Server 2008 R2, Windows Server 2003, Red Hat Enterprise Linux 5.4, SUSE Linux Enterprise Server 11, VMware ESXi 4, VMware ESX 4 |
Processor special features
| Specification | Value |
|---|---|
| CPU configuration (max) | 2 |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel 64 | Yes |
| Intel Clear Video Technology | No |
| Intel Demand Based Switching | Yes |
| Intel Dual Display Capable Technology | No |
| Intel Enhanced Halt State | Yes |
| Intel FDI Technology | No |
| Intel Fast Memory Access | No |
| Intel Flex Memory Access | No |
| Intel Rapid Storage Technology | No |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel® AES New Instructions (Intel® AES-NI) | Yes |
| Intel® Anti-Theft Technology (Intel® AT) | No |
| Intel® Clear Video HD Technology (Intel® CVT HD) | No |
| Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID) | No |
| Intel® Hyper Threading Technology (Intel® HT Technology) | Yes |
| Intel® InTru™ 3D Technology | No |
| Intel® Insider™ | No |
| Intel® My WiFi Technology (Intel® MWT) | No |
| Intel® Quick Sync Video Technology | No |
| Intel® Turbo Boost Technology | 1.0 |
| Intel® Wireless Display (Intel® WiDi) | No |
| Processor ARK ID | 47922 |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
| Number of power supply units | 2 |
| Power requirements | 100 - 240 VAC, 50 - 60 Hz |
| Power supply | 1400 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Operating relative humidity (H-H) | 8 - 90% |
| Storage relative humidity (H-H) | 5 - 95% |
Certificates
| Specification | Value |
|---|---|
| Compliance industry standards | IEEE 802.3, IEEE 802.3ab, IEEE 802.3u |
| Electromagnetic compatibility | FCC (A), CE (A), BSMI (A) |
| Safety | UL/cUL, CB, Nemko/GS |
Weight & dimensions
| Specification | Value |
|---|---|
| Width | 438 mm |
| Depth | 724 mm |
| Height | 88 mm |
| Weight | 30.9 kg |
Packaging content
| Specification | Value |
|---|---|
| Keyboard included | No |
| Mouse included | No |
Other features
| Specification | Value |
|---|---|
| Disk array controller | Intel ICH10R SATA |
| Data transfer rate | 3 Gbit/s |
| Graphics card | G200eW |
| Graphics card family | Matrox |
| Mac compatibility | No |
| Ventilation fan(s) | 4 x 80mm |
