Acer AT 110F2 server

1 TB Tower Intel® Xeon® E3 Family E3-1220 3.1 GHz 4 GB DDR3-SDRAM 450 W

Model 110F2Part no. TT.R7G00.035EAN 4717276741549

116 specifications

ProcessorIntel® Xeon® E3 Family
Memory4 GB
Storage1 TB
Weight12.4 kg
Processor manufacturerIntel
Wi-FiNo

See all specifications

Overview

Processor: Intel® Xeon® E3 Family
Memory: 4 GB
Storage: 1 TB
Weight: 12.4 kg
Processor manufacturer: Intel
Wi-Fi: No

Brand: Acer
Category: Server
Model: 110F2
Part number: TT.R7G00.035
EAN / UPC: 4717276741549
Also known as: Acer AT 110F2 server 1 TB Tower Intel® Xeon® E3 Family E3-1220 3.1 GHz 4 GB DDR3-SDRAM 450 W

Specifications

116 specifications in 16 groups

Processor

Specification	Value
Processor manufacturer	Intel
Processor family	Intel® Xeon® E3 Family
Processor model	E3-1220
Processor frequency	3.1 GHz
Processor boost frequency	3.4 GHz
Processor cores	4
Processor cache	8 MB
Memory channels supported by processor	Dual
Number of processors installed	1
Thermal Design Power (TDP)	80 W
Processor cache type	Smart Cache
System bus rate	5 GT/s
Bus type	DMI
CPU multiplier (bus/core ratio)	31
ECC supported by processor	Yes
Embedded options available	No
Execute Disable Bit	Yes
FSB Parity	No
Idle States	Yes
Maximum internal memory supported by processor	32 GB
Maximum number of PCI Express lanes	20
Memory bandwidth supported by processor (max)	21 GB/s
Memory clock speeds supported by processor	1066,1333 MHz
Memory types supported by processor	DDR3-SDRAM
Processor codename	Sandy Bridge
Processor lithography	32 nm
Processor operating modes	64-bit
Processor package size	37.5 x 37.5 mm
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	4
Supported instruction sets	AVX
Tcase	69.1 °C
Thermal Monitoring Technologies	Yes
Conflict-Free processor	No

Memory

Specification	Value
Internal memory	4 GB
Internal memory type	DDR3-SDRAM
ECC	Yes
Memory layout (slots x size)	2 x 2 GB
Memory slots	4x DIMM

Storage

Specification	Value
Total storage capacity	1 TB
Number of HDDs installed	2
HDD interface	Serial ATA
HDD speed	7200 RPM
Number of HDDs supported	4
RAID support	Yes
RAID levels	0, 1, 1+0, 5
Optical drive type	DVD-ROM

Network

Specification	Value
Wi-Fi	No
Bluetooth	No
Cabling technology	10/100/1000Base-T(X)
Ethernet LAN	Yes
Networking features	Gigabit Ethernet

Ports & interfaces

Specification	Value
Ethernet LAN (RJ-45) ports	1
USB 2.0 ports quantity	6
DisplayPorts quantity	0
Firewire (IEEE 1394) ports	0
PS/2 ports quantity	0
Parallel ports quantity	0
Serial ports quantity	1
VGA (D-Sub) ports quantity	1

Expansion slots

Specification	Value
PCI Express x4 slots	1
PCI Express x8 slots	1
PCI Express x16 slots	1
PCI Express slots version	2.0
PCI slots	1

Design

Specification	Value
Chassis type	Tower

Software

Specification	Value
Compatible operating systems	Windows Server 2003/2008/2008 R2 Red Hat Enterprise Linux 5.4/Novell SUSE/Linux Enterprise Server 11

Processor special features

Specification	Value
CPU configuration (max)	1
Enhanced Intel SpeedStep Technology	Yes
Intel 64	Yes
Intel Clear Video Technology	No
Intel Demand Based Switching	Yes
Intel Dual Display Capable Technology	No
Intel Enhanced Halt State	Yes
Intel FDI Technology	No
Intel Fast Memory Access	Yes
Intel Flex Memory Access	Yes
Intel Identity Protection Technology version	1.00
Intel Rapid Storage Technology	No
Intel Trusted Execution Technology	Yes
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel® AES New Instructions (Intel® AES-NI)	Yes
Intel® Anti-Theft Technology (Intel® AT)	No
Intel® Clear Video HD Technology (Intel® CVT HD)	No
Intel® Clear Video Technology for Mobile Internet Devices (Intel CVT for MID)	No
Intel® Hyper Threading Technology (Intel® HT Technology)	No
Intel® Identity Protection Technology (Intel® IPT)	Yes
Intel® InTru™ 3D Technology	No
Intel® Insider™	No
Intel® My WiFi Technology (Intel® MWT)	No
Intel® Quick Sync Video Technology	No
Intel® Smart Cache	Yes
Intel® Turbo Boost Technology	2.0
Intel® Wireless Display (Intel® WiDi)	No
Processor ARK ID	52269

Power

Specification	Value
Number of power supply units	1
Power supply	450 W

Operational conditions

Specification	Value
Operating temperature (T-T)	5 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	30 - 80%
Storage relative humidity (H-H)	5 - 95%

Certificates

Specification	Value
Compliance industry standards	IEEE 802.3/802.3u/802.3ab
Certification	CE/FCC

Sustainability

Specification	Value
Sustainability certificates	ENERGY STAR

Weight & dimensions

Specification	Value
Width	180 mm
Depth	406 mm
Height	374 mm
Weight	12.4 kg

Packaging content

Specification	Value
Cables included	AC
Keyboard included	No
Mouse included	Yes

Other features

Specification	Value
Mac compatibility	No
Number of drive bays	2 x 5.25"
