W332-Z00 AMD B650E Socket AM5 Mini Tower Black, Grey
Model W332-Z00Part no. 6BW332Z00MR-00EAN 4719331602048
64 specifications
- ColourBlack, Grey
- Built-in processorNo
- Number of DIMM slots4
- Ethernet LANYes
- USB 2.0 ports quantity0
- PCI Express x1 slots1
Overview
- Colour
- Black, Grey
- Built-in processor
- No
- Number of DIMM slots
- 4
- Ethernet LAN
- Yes
- USB 2.0 ports quantity
- 0
- PCI Express x1 slots
- 1
- Brand
- GIGABYTE
- Category
- Server Barebone
- Model
- W332-Z00
- Part number
- 6BW332Z00MR-00
- EAN / UPC
- 4719331602048
- Also known as
- GIGABYTE W332-Z00 AMD B650E Socket AM5 Mini Tower Black, Grey
Specifications
64 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
| Motherboard chipset | AMD B650E |
| Processor socket | Socket AM5 |
| Number of processors supported | 1 |
| Compatible processor series | AMD Ryzen 7000 Series |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 4 |
| Supported memory types | DDR5-SDRAM |
| Supported DIMM module capacities | 32GB |
| Maximum internal memory | 128 GB |
| Memory channels | Dual-channel |
| ECC | Yes |
| Non-ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 4 |
| Hot-swap HDD bays | No |
| Storage drive sizes supported | 3.5,2.5,M.2 |
| Supported storage drive types | HDD & SSD |
| RAID levels | 0, 1, 10 |
| SSD form factor | M.2 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 2.5 Gigabit Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000,2500 Mbit/s |
| LAN controller | Realtek RTL8125, Realtek RTL8111EP |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity | 1 |
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI ports quantity | 1 |
| DisplayPorts quantity | 1 |
| Headphone outputs | 2 |
| Microphone in | Yes |
| Number of SATA III connectors | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x1 slots | 1 |
| PCI Express x16 (Gen 4.x) slots | 1 |
| PCI Express x16 (Gen 5.x) slots | 1 |
| Number of M.2 (M) slots | 2 |
Features
| Specification | Value |
|---|---|
| Audio output channels | 7.1 channels |
| Audio chip | Realtek ALC897 |
| Trusted Platform Module (TPM) | Yes |
Design
| Specification | Value |
|---|---|
| Chassis type | Mini Tower |
| Product colour | Black, Grey |
| LED indicators | HDD, M.2 |
| On/off switch | Yes |
| Reset button | Yes |
| Cooling type | Active |
| Fan diameter | 9.2 cm |
| Number of fans | 2 fan(s) |
Power
| Specification | Value |
|---|---|
| Power supply | 500 W |
| Number of main power supplies | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| DC output current (+5 V) | 20 A |
| DC output current (+12 V) | 41.66 A |
| 80 PLUS certification | 80 PLUS Bronze |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 8 - 80% |
| Operating temperature (T-T) | 0 - 30 °C |
| Storage relative humidity (H-H) | 20 - 95% |
| Storage temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 370 mm |
| Height | 375 mm |
| Width | 198 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 512 mm |
| Package depth | 324 mm |
| Package height | 503 mm |
