S260-NF0 Rack (2U) Black, Grey
Model S260-NF0Part no. 6NS260NF0MR-00EAN 4719331191436
37 specifications
- Weight17 kg
- ColourBlack, Grey
- Number of storage drives supported24
- On-board graphics card modelAspeed AST2520
- Ethernet LANYes
- Ethernet LAN (RJ-45) ports1
Overview
- Weight
- 17 kg
- Colour
- Black, Grey
- Number of storage drives supported
- 24
- On-board graphics card model
- Aspeed AST2520
- Ethernet LAN
- Yes
- Ethernet LAN (RJ-45) ports
- 1
- Brand
- GIGABYTE
- Category
- Server Barebone
- Model
- S260-NF0
- Part number
- 6NS260NF0MR-00
- EAN / UPC
- 4719331191436
- Also known as
- GIGABYTE S260-NF0 Rack (2U) Black, Grey
Specifications
37 specifications in 12 groups
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 24 |
| Hot-swap HDD bays | Yes |
| Number of 2.5" bays | 24 |
| Storage drive sizes supported | 2.5" |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | Aspeed AST2520 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| Ethernet LAN (RJ-45) ports | 1 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x16 slots | 3 |
Features
| Specification | Value |
|---|---|
| Backplanes support | Yes |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84714100 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (2U) |
| Product colour | Black, Grey |
| LED indicators | Yes |
| On/off switch | Yes |
| Reset button | Yes |
| Fan diameter | 8 cm |
| Number of fans | 4 fan(s) |
Power
| Specification | Value |
|---|---|
| Power supply | 800 W |
| Redundant power supply (RPS) support | Yes |
| Number of redundant power supplies installed | 2 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 10-4 A |
| 80 PLUS certification | 80 PLUS Platinum |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 8 - 80% |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 95% |
| Storage temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 695 mm |
| Height | 87 mm |
| Weight | 17 kg |
| Width | 440 mm |
Packaging data
| Specification | Value |
|---|---|
| Package width | 1038 mm |
| Package depth | 697 mm |
| Package height | 311 mm |
| Package weight | 28.8 kg |
