GIGABYTE R183-ZF1-AAJ1 LGA 6096 Rack (1U) Black, Steel
GIGABYTE

R183-ZF1-AAJ1 LGA 6096 Rack (1U) Black, Steel

Model R183-ZF1-AAJ1Part no. 6NR183ZF1DR000AAJ1EAN 4719331855765

50 specifications
  • Weight23.9 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots24
  • Number of storage drives supported14
  • On-board graphics card modelAspeed AST2600
See all specifications

Overview

Weight
23.9 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
24
Number of storage drives supported
14
On-board graphics card model
Aspeed AST2600
Brand
GIGABYTE
Model
R183-ZF1-AAJ1
Part number
6NR183ZF1DR000AAJ1
EAN / UPC
4719331855765
Also known as
GIGABYTE R183-ZF1-AAJ1 LGA 6096 Rack (1U) Black, Steel

Specifications

50 specifications in 12 groups

Processor

Built-in processorNo
Processor socketLGA 6096
Number of processors supported2
Compatible processor seriesAMD EPYC 9004

Memory

Number of DIMM slots24
Supported memory typesGDDR5
Memory channelsDodeca-channel

Storage

Number of storage drives supported14
Hot-swap HDD baysYes
Number of 2.5" bays12
Storage drive sizes supported2.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0

Graphics

On-board graphics card modelAspeed AST2600

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Ethernet LAN (RJ-45) ports0
Mini DisplayPorts quantity1

Expansion slots

PCI Express slots version4.0
Number of M.2 (M) slots2

Features

Trusted Platform Module (TPM)Yes

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsHDD, LAN, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Number of fans9 fan(s)

Power

Power supply2000 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported1
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current13 - 10 A
80 PLUS certification80 PLUS Titanium

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth815 mm
Height43.5 mm
Weight23.9 kg
Width438 mm

Packaging data

Packaging content1 x R183-ZF1-AAJ1 2 x CPU heatsinks 1 x Mini-DP to D-Sub cable 1 x GPU power cable (12VHPWR, 150mm) 1 x 2-Section Rail kit
Package width1043 mm
Package depth594 mm
Package height287 mm
Package weight28.9 kg
