GIGABYTE R183-SF1-AAJ1 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel
GIGABYTE

R183-SF1-AAJ1 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel

Model R183-SF1-AAJ1Part no. 6NR183SF1DR000AAJ1EAN 4719331852306

51 specifications
  • Weight28.8 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots32
  • Number of storage drives supported12
  • On-board graphics card modelAspeed AST2600
See all specifications

Overview

Weight
28.8 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
32
Number of storage drives supported
12
On-board graphics card model
Aspeed AST2600
Brand
GIGABYTE
Model
R183-SF1-AAJ1
Part number
6NR183SF1DR000AAJ1
EAN / UPC
4719331852306
Also known as
GIGABYTE R183-SF1-AAJ1 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel

Specifications

51 specifications in 12 groups

Processor

Built-in processorNo
Motherboard chipsetIntel C741
Processor socketLGA 4677 (Socket E)
Number of processors supported2
Compatible processor seriesIntel® Xeon®

Memory

Number of DIMM slots32
Supported memory typesGDDR5
Memory channelsOcta-channel

Storage

Number of storage drives supported12
Hot-swap HDD baysYes
Number of 2.5" bays12
Storage drive sizes supported2.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2600

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Ethernet LAN (RJ-45) ports0
Mini DisplayPorts quantity1

Expansion slots

PCI Express slots version4.0

Features

Trusted Platform Module (TPM)Yes

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsHDD, LAN, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Number of fans9 fan(s)

Power

Power supply2000 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported1
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current13 - 10 A
80 PLUS certification80 PLUS Titanium

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth815 mm
Height43.5 mm
Weight28.8 kg
Width438 mm

Packaging data

Packaging content1 x R183-SF1-AAJ1 2 x CPU heatsinks 1 x Mini-DP to D-Sub cable 1 x GPU power cable (12VHPWR, 100mm) 6 x Carriers 1 x 2-Section Rail kit
Package width1043 mm
Package depth602 mm
Package height267 mm
Package weight30.8 kg
