GIGABYTE R183-S97-AAD1 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel
GIGABYTE

R183-S97-AAD1 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel

Model R183-S97-AAD1Part no. 6NR183S97DR000AAD1EAN 4719331856496

55 specifications
  • Weight23.2 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots32
  • Number of storage drives supported14
  • On-board graphics card modelAspeed AST2600
See all specifications

Overview

Weight
23.2 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
32
Number of storage drives supported
14
On-board graphics card model
Aspeed AST2600
Brand
GIGABYTE
Model
R183-S97-AAD1
Part number
6NR183S97DR000AAD1
EAN / UPC
4719331856496
Also known as
GIGABYTE R183-S97-AAD1 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel

Specifications

55 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetIntel C741
Processor socketLGA 4677 (Socket E)
Number of processors supported2
Compatible processor seriesIntel® Xeon®

Memory

Number of DIMM slots32
Supported memory typesGDDR5
Memory channelsOcta-channel

Storage

Number of storage drives supported14
Hot-swap HDD baysYes
Number of 2.5" bays8
Storage drive sizes supported2.5,E1.S
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Ethernet LAN (RJ-45) ports2
Mini DisplayPorts quantity1

Expansion slots

PCI Express slots version4.0

Features

Trusted Platform Module (TPM)Yes

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsHDD, LAN, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Number of fans8 fan(s)

Power

Power supply1600 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported1
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current10 - 12 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth815 mm
Height43.5 mm
Weight23.2 kg
Width438 mm

Packaging data

Packaging content1 x R183-S97-AAD1 2 x CPU heatsinks 1 x Mini-DP to D-Sub cable 6 x Carriers 1 x 2-Section Rail kit
Package width1052 mm
Package depth602 mm
Package height267 mm
Package weight28.2 kg
