GIGABYTE R183-S90-AAV2 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel
GIGABYTE

R183-S90-AAV2 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel

Model R183-S90-AAV2Part no. 6NR183S90DR000AAV2EAN 4719331855437

59 specifications
  • ProcessorIntel® Xeon®
  • GraphicsNot available
  • Weight22 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots32
See all specifications

Overview

Processor
Intel® Xeon®
Graphics
Not available
Weight
22 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
32
Brand
GIGABYTE
Model
R183-S90-AAV2
Part number
6NR183S90DR000AAV2
EAN / UPC
4719331855437
Also known as
GIGABYTE R183-S90-AAV2 Intel C741 LGA 4677 (Socket E) Rack (1U) Black, Steel

Specifications

59 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetIntel C741
Processor socketLGA 4677 (Socket E)
Processor manufacturerIntel
Processor familyIntel® Xeon®
Processor generationIntel Xeon Scalable 4th Gen
Number of processors supported2
Compatible processor seriesIntel® Xeon®

Memory

Number of DIMM slots32
Supported memory typesGDDR5
Memory channelsOcta-channel

Storage

Number of storage drives supported4
Hot-swap HDD baysYes
Number of 2.5" bays4
Number of 3.5" bays4
Storage drive sizes supported2.5,3.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0
RAID levels0, 1, 5, 10

Graphics

Discrete graphics card modelNot available
On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports2
Mini DisplayPorts quantity1

Expansion slots

PCI Express slots version4.0

Features

Trusted Platform Module (TPM)Yes

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsHDD, LAN, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Number of fans8 fan(s)

Power

Power supply1600 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported1
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current10 - 12 A
80 PLUS certification80 PLUS Titanium

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth815 mm
Height435 mm
Weight22 kg
Width438 mm

Packaging data

Packaging content1 x R183-S90-AAV2 2 x CPU heatsinks 1 x Mini-DP to D-Sub cable 6 x Carriers 1 x 2-Section Rail kit
Package width1052 mm
Package depth602 mm
Package height267 mm
Package weight24.7 kg
