GIGABYTE R182-P91 LGA 4926 Rack (1U) Black, Steel
GIGABYTE

R182-P91 LGA 4926 Rack (1U) Black, Steel

Model R182-P91Part no. 6NR182P91DR-00EAN 4719331601706

59 specifications
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots32
  • Number of storage drives supported13
  • On-board graphics card modelAspeed AST2600
  • Ethernet LANYes
See all specifications

Overview

Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
32
Number of storage drives supported
13
On-board graphics card model
Aspeed AST2600
Ethernet LAN
Yes
Brand
GIGABYTE
Model
R182-P91
Part number
6NR182P91DR-00
EAN / UPC
4719331601706
Also known as
GIGABYTE R182-P91 LGA 4926 Rack (1U) Black, Steel

Specifications

59 specifications in 13 groups

Processor

Built-in processorNo
Processor socketLGA 4926
Number of processors supported2
Compatible processor seriesAmpere Altra

Memory

Number of DIMM slots32
Supported memory typesDDR4-SDRAM
Maximum RDIMM memory256 GB
Memory channelsOcta-channel

Storage

Number of storage drives supported13
Hot-swap HDD baysYes
Number of 2.5" bays12
Storage drive sizes supported2.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0
SSD form factorM.2

Graphics

On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Ethernet LAN (RJ-45) ports2
Mini DisplayPorts quantity1

Expansion slots

PCI Express x16 (Gen 4.x) slots2
Number of M.2 (M) slots1

Features

Trusted Platform Module (TPM)Yes
Backplanes supportYes
Compatible operating systemsRed Hat Enterprise Linux 8.3 (aarch64) or later; Red Hat Enterprise Linux 8.5 (aarch64) or later; SUSE Linux Enterprise Server 15 SP2 (aarch64) or later; SUSE Linux Enterprise Server 15 SP3 (aarch64) or later; Ubuntu 18.04.5 LTS (aarch64) or later; Ubuntu 20.04.1 LTS (aarch64) or later; Fedora Serve

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, SSD, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Heat sink includedYes
Number of fans8 fan(s)

Power

Power supply1300 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current7 - 12 A
DC output current (+12 V)80.5 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth815 mm
Height43.5 mm
Width438 mm

Packaging data

Packaging content1 x R182-P91; 2 x CPU heatsinks; 1 x 2-Section Rail kit
Package width1045 mm
Package depth595 mm
Package height249 mm
