GIGABYTE R181-T90 server barebone Rack (1U)

GIGABYTE R181-T90 server barebone Rack (1U)

Model R181-T90EAN 889523014691

49 specifications
  • Weight13 kg
  • Built-in processorNo
  • Number of DIMM slots24
  • Number of storage drives supported10
  • On-board graphics card modelAspeed AST2500
  • Ethernet LANYes
See all specifications

Overview

Weight
13 kg
Built-in processor
No
Number of DIMM slots
24
Number of storage drives supported
10
On-board graphics card model
Aspeed AST2500
Ethernet LAN
Yes
Brand
GIGABYTE
Model
R181-T90
Part numbers
R181-T90, 6NR181T90MR-00
EAN / UPC
889523014691
Also known as
GIGABYTE R181-T90 server barebone Rack (1U)

Specifications

49 specifications in 14 groups

Processor

Built-in processorNo
Number of processors supported2
Compatible processor seriesIntel® Xeon®

Memory

Number of DIMM slots24
Supported memory typesDDR4-SDRAM
Maximum internal memory1.53 TB
Supported RDIMM clock speeds2133,2400,2666 MHz
Memory voltage1.2 V
ECCYes

Storage

Number of storage drives supported10
Hot-swap HDD baysYes
Storage drive sizes supported2.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial Attached SCSI (SAS), Serial ATA III
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates1000 Mbit/s

Ports & interfaces

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Ethernet LAN (RJ-45) ports3
VGA (D-Sub) ports quantity1

Expansion slots

PCI Express x8 (Gen 3.x) slots2
PCI Express x16 (Gen 3.x) slots3

Logistics data

Harmonized System (HS) code84714100

Processor special features

Intelligent Platform Management Interface (IPMI) supportYes

Design

Chassis typeRack (1U)
LED indicatorsYes
Reset buttonYes
Fan diameter4 cm
Number of fans8 fan(s)
Redundant fans supportYes

Power

Power supply1200 W
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth730 mm
Height43.5 mm
Weight13 kg
Width438 mm

Packaging data

Package width588 mm
Package depth959 mm
Package height248 mm
