GIGABYTE R163-S35-AAC1 LGA 4677 (Socket E) Rack (1U) Black, Steel
GIGABYTE

R163-S35-AAC1 LGA 4677 (Socket E) Rack (1U) Black, Steel

Model R163-S35-AAC1Part no. 6NR163S35DR000ABC1

55 specifications
  • Weight19.1 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots16
  • Number of storage drives supported13
  • On-board graphics card modelAspeed AST2600
See all specifications

Overview

Weight
19.1 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
16
Number of storage drives supported
13
On-board graphics card model
Aspeed AST2600
Brand
GIGABYTE
Model
R163-S35-AAC1
Part number
6NR163S35DR000ABC1
Also known as
GIGABYTE R163-S35-AAC1 LGA 4677 (Socket E) Rack (1U) Black, Steel

Specifications

55 specifications in 13 groups

Processor

Built-in processorNo
Processor socketLGA 4677 (Socket E)
Number of processors supported1
Compatible processor seriesIntel® Xeon®

Memory

Number of DIMM slots16
Supported memory typesGDDR5
Memory channelsOcta-channel

Storage

Number of storage drives supported13
Hot-swap HDD baysYes
Number of 2.5" bays12
Storage drive sizes supported2.5,3.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0
RAID levels0, 1, 5, 10
SSD form factorM.2

Graphics

On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I210-AT

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Ethernet LAN (RJ-45) ports1
Mini DisplayPorts quantity1

Expansion slots

Number of M.2 (M) slots1

Features

Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Heat sink includedYes
Number of fans6 fan(s)

Power

Power supply1300 W
Number of main power supplies2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current12 - 8 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth710 mm
Height435 mm
Weight19.1 kg
Width438 mm

Packaging data

Packaging content1 x R163-S35-AAC1 1 x CPU heatsink 1 x Mini-DP to D-Sub cable 3 x Carriers 1 x 2-Section Rail kit
Package width982 mm
Package depth594 mm
Package height250 mm
Package weight21.1 kg
