GIGABYTE R162-Z10 Rev. 100
GIGABYTE

R162-Z10 Rev. 100

Model R162-Z10 Rev. 100Part no. 6NR162Z10MR-00EAN 4719331191160

62 specifications
  • Weight12.6 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots8
  • Number of storage drives supported13
  • On-board graphics card modelAspeed AST2500
See all specifications

Overview

Weight
12.6 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
8
Number of storage drives supported
13
On-board graphics card model
Aspeed AST2500
Brand
GIGABYTE
Model
R162-Z10 Rev. 100
Part number
6NR162Z10MR-00
EAN / UPC
4719331191160
Also known as
GIGABYTE R162-Z10 Rev. 100 AMD SoC Socket SP3 Rack (1U) Black, Steel

Specifications

62 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetAMD SoC
Processor socketSocket SP3
Number of processors supported1
Compatible processor seriesAMD EPYC 7002, AMD EPYC 7001 Series

Memory

Number of DIMM slots8
Supported memory typesDDR4-SDRAM
Memory channelsOcta-channel

Storage

Number of storage drives supported13
Hot-swap HDD baysYes
Number of 2.5" bays10
Storage drive sizes supported2.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 3.0, Serial Attached SCSI (SAS)
SSD form factorM.2

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity3
Ethernet LAN (RJ-45) ports2
VGA (D-Sub) ports quantity1

Expansion slots

PCI Express x16 (Gen 3.x) slots2
PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots3

Features

Trusted Platform Module (TPM)Yes
Backplanes supportYes
Compatible operating systemsCitrix Hypervisor 8.1.0 or later; Red Hat Enterprise Linux 7.6 or later; Red Hat Enterprise Linux 8.0 or later; Red Hat Enterprise Linux 9.0 or later; SUSE Linux Enterprise Server 12 SP4 or later; SUSE Linux Enterprise Server 15 SP1 or later; Ubuntu 16.04.6 LTS or later; Ubuntu 18.04.3 LTS or later;

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, SSD, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Heat sink includedYes
Number of fans8 fan(s)

Power

Power supply1200 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current7 - 12 A
DC output current (+12 V)97 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth730 mm
Height43.5 mm
Weight12.6 kg
Width438 mm

Packaging data

Packaging content1 x R162-Z10; 1 x CPU heatsink; 1 x 2-Section Rail kit
Package width985 mm
Package depth588 mm
Package height250 mm
Package weight21 kg
