GIGABYTE R161-R12 Intel® X299 LGA 2066 (Socket R4) Rack (1U)
GIGABYTE

R161-R12 Intel® X299 LGA 2066 (Socket R4) Rack (1U)

Model R161-R12Part no. 6NR161R12MR-00EAN 4719331181659

52 specifications
  • ProcessorIntel
  • Weight13.2 kg
  • Built-in processorNo
  • Number of DIMM slots8
  • Number of storage drives supported2
  • On-board graphics card modelAspeed AST2500
See all specifications

Overview

Processor
Intel
Weight
13.2 kg
Built-in processor
No
Number of DIMM slots
8
Number of storage drives supported
2
On-board graphics card model
Aspeed AST2500
Brand
GIGABYTE
Model
R161-R12
Part number
6NR161R12MR-00
EAN / UPC
4719331181659
Also known as
GIGABYTE R161-R12 Intel® X299 LGA 2066 (Socket R4) Rack (1U)

Specifications

52 specifications in 14 groups

Processor

Built-in processorNo
Motherboard chipsetIntel® X299
Processor socketLGA 2066 (Socket R4)
Processor manufacturerIntel
Processor familyIntel
Number of processors supported1

Memory

Number of DIMM slots8
Supported memory typesDDR4-SDRAM
Supported RDIMM clock speeds2133,2400,2666 MHz
Memory channelsQuad-channel
Non-ECCYes

Storage

Number of storage drives supported2
Hot-swap HDD baysYes
Storage drive sizes supported2.5"
Supported storage drive typesHDD
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports2
VGA (D-Sub) ports quantity1
COM ports quantity1

Expansion slots

PCI Express slots version3.0
PCI Express x16 slots3
Number of M.2 (M) slots2

Features

Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Backplanes supportYes
Compatible operating systemsWindows Server 2012 R2 with Update Windows Server 2016 x64 Windows 10 x64 Red Hat Enterprise Linux 6.9 x64 Red Hat Enterprise Linux 7.5 x64 SUSE Linux Enterprise Server 11.4 x64 SUSE Linux Enterprise Server 12.3 x64 Ubuntu 16.04.5 LTS x64 Ubuntu 18.04 LTS x64 VMware ESXi 6.5

Logistics data

Harmonized System (HS) code84714100

Design

Chassis typeRack (1U)
LED indicatorsHDD, LAN, Status
Fan diameter4 cm
Number of fans11 fan(s)

Power

Power supply1100 W
Number of main power supplies2
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
DC output current (+5 V)3 A

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth43.5 mm
Height730 mm
Weight13.2 kg
Width438 mm

Packaging data

Packaging content1 x R161-R12 1 x Rail kit
Package width985 mm
Package depth588 mm
Package height250 mm
Package weight21.8 kg
