R112-X30 Intel C252 LGA 1200 (Socket H5) Rack (1U) Black, Steel
GIGABYTE

R112-X30 Intel C252 LGA 1200 (Socket H5) Rack (1U) Black, Steel

Model R112-X30Part no. 6NR112X30MR-00EAN 4719331602260

63 specifications
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots4
  • Number of storage drives supported5
  • On-board graphics card modelAspeed AST2500
  • Ethernet LANYes
See all specifications

Overview

Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
4
Number of storage drives supported
5
On-board graphics card model
Aspeed AST2500
Ethernet LAN
Yes
Brand
GIGABYTE
Model
R112-X30
Part number
6NR112X30MR-00
EAN / UPC
4719331602260
Also known as
GIGABYTE R112-X30 Intel C252 LGA 1200 (Socket H5) Rack (1U) Black, Steel

Specifications

63 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetIntel C252
Processor socketLGA 1200 (Socket H5)
Number of processors supported1
Compatible processor seriesIntel Xeon E
Intel Xeon seriesE-2300

Memory

Number of DIMM slots4
Supported memory typesDDR4-SDRAM
Memory channelsDual-channel
ECCYes
Non-ECCYes

Storage

Number of storage drives supported5
Hot-swap HDD baysYes
Number of 2.5" bays4
Storage drive sizes supported2.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 3.0
RAID levels0, 1, 5, 10
SSD form factorM.2

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I210-AT

Ports & interfaces

USB 2.0 ports quantity4
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Ethernet LAN (RJ-45) ports2
VGA (D-Sub) ports quantity1
COM ports quantity1

Expansion slots

PCI Express x16 (Gen 4.x) slots1
Number of M.2 (M) slots1

Features

Trusted Platform Module (TPM)Yes
Compatible operating systemsRed Hat Enterprise Linux 6.9; Red Hat Enterprise Linux 7.3; SUSE Linux Enterprise Server 11.2; SUSE Linux Enterprise Server 12.2; Ubuntu 16.04.6 LTS; Ubuntu 18.04.2 LTS; VMware 6.5; Windows Server 2016; Windows Server 2019

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, SSD, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter4 cm
Heat sink includedYes
Number of fans2 fan(s)

Power

Power supply350 W
Number of main power supplies1
Redundant power supply (RPS) supportYes
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current3 - 6 A
DC output current (+5 V)14 A
DC output current (+12 V)29 A
80 PLUS certification80 PLUS Bronze

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 30 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth393.2 mm
Height43.5 mm
Width430 mm

Packaging data

Packaging content1 x R112-X30; 1 x CPU heatsink
Package width592 mm
Package depth518 mm
Package height155 mm
