GIGABYTE H261-H61 Intel® C621 LGA 3647 (Socket P) Rack (2U)
GIGABYTE

H261-H61 Intel® C621 LGA 3647 (Socket P) Rack (2U)

Model H261-H61Part no. 6NH261H61MR-00EAN 4719331281021

46 specifications
  • ProcessorIntel® Xeon® Scalable
  • Weight35 kg
  • Built-in processorNo
  • Number of DIMM slots16
  • Number of storage drives supported24
  • On-board graphics card modelAspeed AST2500
See all specifications

Overview

Processor
Intel® Xeon® Scalable
Weight
35 kg
Built-in processor
No
Number of DIMM slots
16
Number of storage drives supported
24
On-board graphics card model
Aspeed AST2500
Brand
GIGABYTE
Model
H261-H61
Part number
6NH261H61MR-00
EAN / UPC
4719331281021
Also known as
GIGABYTE H261-H61 Intel® C621 LGA 3647 (Socket P) Rack (2U)

Specifications

46 specifications in 14 groups

Processor

Built-in processorNo
Motherboard chipsetIntel® C621
Processor socketLGA 3647 (Socket P)
Processor manufacturerIntel
Processor familyIntel® Xeon® Scalable
Number of processors supported8

Memory

Number of DIMM slots16
Supported memory typesDDR4-SDRAM
Supported DIMM module capacities64GB, 128GB
Maximum RDIMM memory64 GB
Supported RDIMM clock speeds2133,2400,2666,2933 MHz
Memory channelsHexa-channel

Storage

Number of storage drives supported24
Hot-swap HDD baysYes
Number of 2.5" bays24
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet LAN data rates10,100,1000 Mbit/s

Ports & interfaces

Ethernet LAN (RJ-45) ports4
VGA (D-Sub) ports quantity4

Expansion slots

PCI Express slots version3.0
PCI Express x8 slots4
PCI Express x16 slots8

Features

Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Backplanes supportYes
Compatible operating systemsWindows Server 2012 R2 with Update Windows Server 2016 Windows Server 2019 Red Hat Enterprise Linux 6.9 (x64) or later Red Hat Enterprise Linux 7.3 (x64) or later Red Hat Enterprise Linux 8.0 (x64) or later SUSE Linux Enterprise Server 11.4 (x64) or later SUSE Linux Enterprise Server 12.2 (x64) or l

Logistics data

Harmonized System (HS) code84714100

Design

Chassis typeRack (2U)
LED indicatorsPower, Status

Power

Power supply2200 W
Number of main power supplies2
AC input voltage200 - 240 V
AC input frequency47 - 63 Hz
DC output current (+12 V)95.6 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth87.5 mm
Height820 mm
Weight35 kg
Width440 mm

Packaging data

Packaging content1 x H261-H61 8 x CPU heatsinks 1 x Rail Kit 1 x VROC module 8 x Non-Fabric CPU carrier
