GIGABYTE H233-Z80-AAN1 AMD SoC Socket SP5 Rack (2U) Black, Steel
GIGABYTE

H233-Z80-AAN1 AMD SoC Socket SP5 Rack (2U) Black, Steel

Model H233-Z80-AAN1Part no. 6NH233Z80DR000AAN1EAN 4719331856731

58 specifications
  • Weight59.1 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots48
  • Number of storage drives supported4
  • On-board graphics card modelAspeed AST2600
See all specifications

Overview

Weight
59.1 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
48
Number of storage drives supported
4
On-board graphics card model
Aspeed AST2600
Brand
GIGABYTE
Model
H233-Z80-AAN1
Part number
6NH233Z80DR000AAN1
EAN / UPC
4719331856731
Also known as
GIGABYTE H233-Z80-AAN1 AMD SoC Socket SP5 Rack (2U) Black, Steel

Specifications

58 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetAMD SoC
Processor socketSocket SP5
Number of processors supported4
Compatible processor seriesAMD EPYC 9004

Memory

Number of DIMM slots48
Supported memory typesDDR5-SDRAM
Memory channelsDodeca-channel

Storage

Number of storage drives supported4
Hot-swap HDD baysYes
Number of 2.5" bays4
Storage drive sizes supported2.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesPCI Express 4.0
SSD form factor2.5"

Graphics

On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports4
Mini DisplayPorts quantity2

Expansion slots

PCI Express x16 (Gen 5.x) slots6

Features

Trusted Platform Module (TPM)Yes
Backplanes supportYes

Design

Chassis typeRack (2U)
Product colourBlack, Steel
LED indicatorsStatus
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter8 cm
Heat sink includedYes
Number of fans4 fan(s)

Power

Power supply2600 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current15 A
80 PLUS certification80 PLUS Titanium

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 30 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth877 mm
Height87.5 mm
Weight59.1 kg
Width440 mm

Packaging data

Packaging content1 x H233-Z80-AAN1; 4 x CPU heatsinks; 1 x Mini-DP to D-Sub cable; 4 x GPU power cables (CPU 8pin, 400mm); 1 x 3-Section Rail kit
Package width1184 mm
Package depth706 mm
Package height394 mm
Package weight64.1 kg
