GIGABYTE G481-H81 Intel® C621 LGA 3647 (Socket P) Rack (4U)
GIGABYTE

G481-H81 Intel® C621 LGA 3647 (Socket P) Rack (4U)

Model G481-H81Part no. 6NG481H81MR-00EAN 4719331181697

51 specifications
  • ProcessorIntel® Xeon® Scalable
  • Built-in processorNo
  • Number of DIMM slots24
  • Number of storage drives supported12
  • On-board graphics card modelAspeed AST2500
  • Ethernet LANYes
See all specifications

Overview

Processor
Intel® Xeon® Scalable
Built-in processor
No
Number of DIMM slots
24
Number of storage drives supported
12
On-board graphics card model
Aspeed AST2500
Ethernet LAN
Yes
Brand
GIGABYTE
Model
G481-H81
Part number
6NG481H81MR-00
EAN / UPC
4719331181697
Also known as
GIGABYTE G481-H81 Intel® C621 LGA 3647 (Socket P) Rack (4U)

Specifications

51 specifications in 14 groups

Processor

Built-in processorNo
Motherboard chipsetIntel® C621
Processor socketLGA 3647 (Socket P)
Processor manufacturerIntel
Processor familyIntel® Xeon® Scalable
Number of processors supported2

Memory

Number of DIMM slots24
Supported memory typesDDR4-SDRAM
Supported DIMM module capacities32GB, 64GB, 128GB
Supported RDIMM clock speeds2133,2400,2666,2933 MHz
Memory voltage1.2 V

Storage

Number of storage drives supported12
Hot-swap HDD baysYes
Number of 2.5" bays12
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet interface type10 Gigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2, Intel® X550

Ports & interfaces

Ethernet LAN (RJ-45) ports4
VGA (D-Sub) ports quantity1

Expansion slots

PCI Express slots version3.0
PCI Express x16 slots10

Features

Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0
Backplanes supportYes
Compatible operating systemsWindows Server 2012 R2 with Update Windows Server 2016 Windows Server 2019 Red Hat Enterprise Linux 6.9 (x64) or later Red Hat Enterprise Linux 7.3 (x64) or later Red Hat Enterprise Linux 8.0 (x64) or later SUSE Linux Enterprise Server 11.4 (x64) or later SUSE Linux Enterprise Server 12.2 (x64) or l

Logistics data

Harmonized System (HS) code84714100

Design

Chassis typeRack (4U)
LED indicatorsHDD, LAN, Power, Status
Fan diameter6 cm
Number of fans6 fan(s)

Power

Power supply1600 W
Number of main power supplies3
AC input voltage200 - 240 V
AC input frequency50 - 60 Hz
Input current9.5 A
DC output current (+12 V)2.1 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth176 mm
Height880 mm
Width448 mm

Packaging data

Packaging content1 x G481-H81 2 x CPU heatsinks 1 x Rail kit 2 x Non-Fabric CPU carrier
Package width1091 mm
Package depth591 mm
Package height406 mm
