GIGABYTE G293-Z42-IAP1 AMD SoC Socket SP5 Rack (2U) Black, Steel
GIGABYTE

G293-Z42-IAP1 AMD SoC Socket SP5 Rack (2U) Black, Steel

Model G293-Z42-IAP1Part no. 6NG293Z42DR000IAP1EAN 4719331859473

52 specifications
  • Weight35 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots24
  • Number of storage drives supported8
  • On-board graphics card modelAspeed AST2600
See all specifications

Overview

Weight
35 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
24
Number of storage drives supported
8
On-board graphics card model
Aspeed AST2600
Brand
GIGABYTE
Model
G293-Z42-IAP1
Part number
6NG293Z42DR000IAP1
EAN / UPC
4719331859473
Also known as
GIGABYTE G293-Z42-IAP1 AMD SoC Socket SP5 Rack (2U) Black, Steel

Specifications

52 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetAMD SoC
Processor socketSocket SP5
Number of processors supported2
Compatible processor seriesAMD EPYC 9004

Memory

Number of DIMM slots24
Supported memory typesDDR5-SDRAM
Memory channelsDodeca-channel

Storage

Number of storage drives supported8
Hot-swap HDD baysYes
Number of 2.5" bays8
Storage drive sizes supported2.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, Serial Attached SCSI (SAS), PCI Express 5.0

Graphics

On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet, 10 Gigabit Ethernet
Ethernet LAN data rates10,100,1000,10000 Mbit/s
LAN controllerBroadcom BCM57416

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports2
VGA (D-Sub) ports quantity1

Expansion slots

PCI Express x16 (Gen 5.x) slots6

Features

Trusted Platform Module (TPM)Yes
Backplanes supportYes

Design

Chassis typeRack (2U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, SSD, System
On/off switchYes
Reset buttonYes
Heat sink includedYes

Power

Power supply3000 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current15.5 A
80 PLUS certification80 PLUS Titanium

Operational conditions

Operating temperature (T-T)25 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth800 mm
Height87.5 mm
Weight35 kg
Width448 mm

Packaging data

Packaging content1 x G293-Z42-IAP1; 2 x CPU heatsinks; 4 x GPU power cables (12VHPWR, 250mm); 4 x GPU power cables (12VHPWR, 280mm)
Package width1138 mm
Package depth730 mm
Package height275 mm
