GIGABYTE G292-Z20 AMD SoC Socket SP3 Rack (2U) Black, Steel
GIGABYTE

G292-Z20 AMD SoC Socket SP3 Rack (2U) Black, Steel

Model G292-Z20Part no. 6NG292Z20MR-00EAN 4719331600099

61 specifications
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots8
  • On-board graphics card modelAspeed AST2500
  • Ethernet LANYes
  • USB 2.0 ports quantity0
See all specifications

Overview

Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
8
On-board graphics card model
Aspeed AST2500
Ethernet LAN
Yes
USB 2.0 ports quantity
0
Brand
GIGABYTE
Model
G292-Z20
Part number
6NG292Z20MR-00
EAN / UPC
4719331600099
Also known as
GIGABYTE G292-Z20 AMD SoC Socket SP3 Rack (2U) Black, Steel

Specifications

61 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetAMD SoC
Processor socketSocket SP3
Number of processors supported1
Compatible processor seriesAMD EPYC 7002

Memory

Number of DIMM slots8
Supported memory typesDDR4-SDRAM
Maximum RDIMM memory128 GB
Memory channelsOcta-channel

Storage

Number of storage drives supported8
Hot-swap HDD baysYes
Number of 2.5" bays8
Storage drive sizes supported2.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesPCI Express 3.0, Serial ATA, Serial Attached SCSI (SAS)
SSD form factorM.2

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet, 10 Gigabit Ethernet
Ethernet LAN data rates10,100,1000,10000 Mbit/s
LAN controllerMellanox ConnectX-4 Lx

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports0
VGA (D-Sub) ports quantity1
SFP+ module slots quantity2

Expansion slots

PCI Express x16 (Gen 4.x) slots10
Number of M.2 (M) slots1

Features

Trusted Platform Module (TPM)Yes
Backplanes supportYes
Compatible operating systemsWindows Server 2016 (X2APIC/256T not supported); Windows Server 2019; Red Hat Enterprise Linux 7.6 or later; Red Hat Enterprise Linux 8.0 or later; Red Hat Enterprise Linux 9.0 or later; SUSE Linux Enterprise Server 12 SP4 or later; SUSE Linux Enterprise Server 15 SP1 or later; Ubuntu 16.04.6 LTS or

Design

Chassis typeRack (2U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter8 cm
Heat sink includedYes
Number of fans8 fan(s)

Power

Power supply2200 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current12.6 - 14 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth800 mm
Height87.5 mm
Width448 mm

Packaging data

Packaging content1 x G292-Z20; 1 x CPU heatsink; 1 x L-shape Rail kit
Package width1133 mm
Package depth724 mm
Package height261 mm
Package weight34.1 kg
