GIGABYTE G292-280-IAP1 Intel C621A LGA 4189 Rack (2U) Black, Steel
GIGABYTE

G292-280-IAP1 Intel C621A LGA 4189 Rack (2U) Black, Steel

Model G292-280-IAP1Part no. 6NG292280DR000IAP1EAN 4719331849504

55 specifications
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots24
  • Number of storage drives supported8
  • On-board graphics card modelAspeed AST2600
  • Ethernet LANYes
See all specifications

Overview

Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
24
Number of storage drives supported
8
On-board graphics card model
Aspeed AST2600
Ethernet LAN
Yes
Brand
GIGABYTE
Model
G292-280-IAP1
Part number
6NG292280DR000IAP1
EAN / UPC
4719331849504
Also known as
GIGABYTE G292-280-IAP1 Intel C621A LGA 4189 Rack (2U) Black, Steel

Specifications

55 specifications in 13 groups

Processor

Built-in processorNo
Motherboard chipsetIntel C621A
Processor socketLGA 4189
Number of processors supported2
Compatible processor seriesIntel® Xeon®

Memory

Number of DIMM slots24
Supported memory typesDDR4-SDRAM
Maximum RDIMM memory128 GB
Memory channelsOcta-channel

Storage

Number of storage drives supported8
Hot-swap HDD baysYes
Number of 2.5" bays4
Number of 3.5" bays4
Storage drive sizes supported2.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesPCI Express 4.0, Serial ATA, Serial Attached SCSI (SAS)
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet, 10 Gigabit Ethernet
Ethernet LAN data rates10,100,1000,10000 Mbit/s
LAN controllerIntel X710-AT2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports2
VGA (D-Sub) ports quantity1

Expansion slots

PCI Express x16 (Gen 4.x) slots10

Features

Trusted Platform Module (TPM)Yes
Backplanes supportYes
Compatible operating systemsCitrix Hypervisor 8.2.0 or later; Red Hat Enterprise Linux 7.9 or later; Red Hat Enterprise Linux 8.2 or later; Red Hat Enterprise Linux 9.0 or later; SUSE Linux Enterprise Server 12 SP5 or later; SUSE Linux Enterprise Server 15 SP2 or later; Ubuntu 20.04 LTS or later; Ubuntu 22.04 LTS or later; VMw

Design

Chassis typeRack (2U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, Status
On/off switchYes
Reset buttonYes
Heat sink includedYes

Power

Power supply3000 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current15.5 A
80 PLUS certification80 PLUS Titanium

Operational conditions

Operating temperature (T-T)25 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth800 mm
Height87.5 mm
Width448 mm

Packaging data

Packaging content1 x G292-280-IAP1; 2 x CPU heatsinks
Package width1133 mm
Package depth724 mm
Package height261 mm
