GIGABYTE G242-P34 LGA 4926 Rack (2U) Black, Steel
GIGABYTE

G242-P34 LGA 4926 Rack (2U) Black, Steel

Model G242-P34Part no. 6NG242P34MR-00-1T0EAN 4719331601447

55 specifications
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots16
  • Number of storage drives supported6
  • On-board graphics card modelAspeed AST2500
  • Ethernet LANYes
See all specifications

Overview

Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
16
Number of storage drives supported
6
On-board graphics card model
Aspeed AST2500
Ethernet LAN
Yes
Brand
GIGABYTE
Model
G242-P34
Part numbers
6NG242P34MR-00-1T0, 6NG242P34MR-00
EAN / UPC
4719331601447
Also known as
GIGABYTE G242-P34 LGA 4926 Rack (2U) Black, Steel

Specifications

55 specifications in 13 groups

Processor

Built-in processorNo
Processor socketLGA 4926
Number of processors supported1
Compatible processor seriesAmpere Altra

Memory

Number of DIMM slots16
Supported memory typesDDR4-SDRAM
Maximum RDIMM memory256 GB
Memory channelsOcta-channel

Storage

Number of storage drives supported6
Hot-swap HDD baysYes
Number of 2.5" bays4
Storage drive sizes supported2.5,3.5"
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0
SSD form factorM.2

Graphics

On-board graphics card modelAspeed AST2500

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports2
VGA (D-Sub) ports quantity1

Expansion slots

PCI Express x16 (Gen 4.x) slots7
PCI Express x8 (Gen 4.x) slots1
Number of M.2 (M) slots2

Features

Trusted Platform Module (TPM)Yes
Compatible operating systemsRed Hat Enterprise Linux 8.3 (aarch64) or later; Red Hat Enterprise Linux 8.5 (aarch64) or later; CentOS 8.3-2011 (aarch64) or later; CentOS-8.4.2105 (aarch64) or later; CentOS-8.5.2111 (aarch64) or later; SUSE Linux Enterprise Server 15 SP2 (aarch64) or later; SUSE Linux Enterprise Server 15 SP3 (a

Design

Chassis typeRack (2U)
Product colourBlack, Steel
LED indicatorsLAN, HDD, Status
On/off switchYes
Reset buttonYes
Cooling typeActive
Fan diameter8 cm
Heat sink includedYes
Number of fans5 fan(s)

Power

Power supply1600 W
Number of main power supplies2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current9.5 - 12 A
80 PLUS certification80 PLUS Titanium

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth820 mm
Height87.5 mm
Width438 mm

Packaging data

Packaging content1 x G242-P34; 1 x CPU heatsink; 1 x 2-Section Rail kit
Package width1077 mm
Package depth679 mm
Package height300 mm
