E152-ZE1 Intel SoC Socket SP3 Rack (1U) Black, Steel
GIGABYTE

E152-ZE1 Intel SoC Socket SP3 Rack (1U) Black, Steel

Model E152-ZE1Part no. 6NE152ZE1MR-00-AEAN 4719331601645

57 specifications
  • Weight7.7 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots8
  • Number of storage drives supported4
  • On-board graphics card modelAspeed AST2600
See all specifications

Overview

Weight
7.7 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
8
Number of storage drives supported
4
On-board graphics card model
Aspeed AST2600
Brand
GIGABYTE
Model
E152-ZE1
Part number
6NE152ZE1MR-00-A
EAN / UPC
4719331601645
Also known as
GIGABYTE E152-ZE1 Intel SoC Socket SP3 Rack (1U) Black, Steel

Specifications

57 specifications in 12 groups

Processor

Built-in processorNo
Motherboard chipsetIntel SoC
Processor socketSocket SP3
Number of processors supported1
Compatible processor seriesAMD EPYC 7003, AMD EPYC 7002

Memory

Number of DIMM slots8
Supported memory typesDDR4L-SDRAM
Memory channelsOcta-channel

Storage

Number of storage drives supported4
Hot-swap HDD baysYes
Number of 2.5" bays2
Storage drive sizes supported2.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, PCI Express 4.0
SSD form factorM.2

Graphics

On-board graphics card modelAspeed AST2600

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports2
Mini DisplayPorts quantity1

Expansion slots

PCI Express x16 (Gen 4.x) slots3
Number of M.2 (M) slots2

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsStatus
On/off switchYes
Cooling typeActive
Fan diameter4 cm
Heat sink includedYes
Number of fans6 fan(s)

Power

Power supply1000 W
Number of main power supplies2
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
Number of redundant power supplies installed2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
Input current8 - 15 A
DC output current (+12 V)83.3 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)8 - 80%
Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 95%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth400 mm
Height43.5 mm
Weight7.7 kg
Width438 mm

Packaging data

Packaging content1 x E152-ZE1; 1 x CPU heatsink
Package width628 mm
Package depth549 mm
Package height200 mm
Package weight11.8 kg
