PRIMERGY TX2550 M5
Model PRIMERGY TX2550 M5Part no. LKN:T2555SC220IN
31 specifications
- ColourBlack, Red
- Motherboard chipsetIntel® C624
- Number of DIMM slots12
- Number of storage drives supported8
- Ethernet LANYes
- USB 2.0 ports quantity0
Overview
- Colour
- Black, Red
- Motherboard chipset
- Intel® C624
- Number of DIMM slots
- 12
- Number of storage drives supported
- 8
- Ethernet LAN
- Yes
- USB 2.0 ports quantity
- 0
- Brand
- Fujitsu
- Category
- Server Barebone
- Model
- PRIMERGY TX2550 M5
- Part numbers
- LKN:T2555SC220IN, LKN:T2555SC240IN, LKN:T2555SC250IN, LKN:T2555SC230IN, LKN:T2555SC450IN
- Also known as
- Fujitsu PRIMERGY TX2550 M5 Intel® C624 LGA 3647 (Socket P) Tower Black, Red
Specifications
31 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Motherboard chipset | Intel® C624 |
| Processor socket | LGA 3647 (Socket P) |
| Processor manufacturer | Intel |
| Number of processors supported | 2 |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 12 |
| Supported memory types | DDR4-SDRAM |
| Maximum internal memory | 1.5 TB |
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 8 |
| Hot-swap HDD bays | Yes |
| Number of 2.5" bays | 8 |
| Storage drive sizes supported | 2.5,3.5" |
| RAID levels | 0, 1, 5, 6, 10, 50, 60 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 6 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 0 |
Features
| Specification | Value |
|---|---|
| Embedded options available | Yes |
| Compatible operating systems | Microsoft Hyper-V Server 2016 Microsoft Windows Server 2016 Datacenter Microsoft Windows Server 2016 Standard Microsoft Windows Server 2016 Essentials Microsoft Windows Storage Server 2016 Standard Microsoft Hyper-V Server 2012 R2 Microsoft Windows Server 2012 R2 Datacenter Microsoft Windows Server |
Processor special features
| Specification | Value |
|---|---|
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black, Red |
| Certification | CB, RoHS, WEEE, GS, CE, CSAc/us, FCC Class A, VCCI, KN32, KN35, CCC, C-Tick |
Power
| Specification | Value |
|---|---|
| Redundant power supply (RPS) support | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 10 - 85% |
| Operating temperature (T-T) | 5 - 45 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 177 mm |
| Height | 736 mm |
| Width | 448 mm |
