ASUS TS700-E9-RS8 server barebone Intel® C621 LGA 3647 (Socket P) Tower (5U) Black, Grey
ASUS

TS700-E9-RS8 server barebone Intel® C621 LGA 3647 (Socket P) Tower (5U) Black, Grey

Model TS700-E9-RS8EAN 4718017100632

43 specifications
  • ProcessorIntel® Xeon® Scalable
  • Weight18.3 kg
  • ColourBlack, Grey
  • Built-in processorYes
  • Number of DIMM slots12
  • Number of storage drives supported8
See all specifications

Overview

Processor
Intel® Xeon® Scalable
Weight
18.3 kg
Colour
Black, Grey
Built-in processor
Yes
Number of DIMM slots
12
Number of storage drives supported
8
Brand
ASUS
Model
TS700-E9-RS8
Part numbers
TS700-E9-RS8, 90SF00K1-M00360, 90SF00K1-M00140
EAN / UPC
4718017100632, 192876391419, 4718017200912
Also known as
ASUS TS700-E9-RS8 server barebone Intel® C621 LGA 3647 (Socket P) Tower (5U) Black, Grey

Specifications

43 specifications in 13 groups

Processor

Built-in processorYes
Motherboard chipsetIntel® C621
Processor socketLGA 3647 (Socket P)
Processor familyIntel® Xeon® Scalable
Number of processors supported2
System bus rate10.4 GT/s

Memory

Number of DIMM slots12
Supported memory typesDDR4-SDRAM
Supported DIMM module capacities8GB, 16GB, 32GB, 64GB
Maximum internal memory1.53 TB
Maximum RDIMM memory768 GB
Supported RDIMM clock speeds2666,2933 MHz

Storage

Number of storage drives supported8
Hot-swap HDD baysYes
Number of 3.5" bays8
Storage drive sizes supported3.5"
Supported storage drive interfacesSerial ATA, Serial Attached SCSI (SAS)

Graphics

On-board graphics card modelAspeed AST2500
On-board graphics card memory64 MB

Network

LAN controllerIntel® I210-AT

Ports & interfaces

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity6
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity2
Ethernet LAN (RJ-45) ports2
PS/2 ports quantity1
S/PDIF out portYes

Expansion slots

PCI Express slots version3.0
PCI Express x16 (Gen 3.x) slots7

Design

Chassis typeTower (5U)
Product colourBlack, Grey
LED indicatorsYes
On/off switchYes
CertificationBSMI, CE, RCM, FCC(Class A)

Power

Power supply800 W

Operational conditions

Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 90%
Storage temperature (T-T)-40 - 70 °C

Weight & dimensions

Depth545 mm
Height255 mm
Weight18.3 kg
Width217.5 mm

Packaging data

Package weight23.1 kg

Other features

Optical drive supportedYes
