TS100-E11-PI4 server barebone Intel C256 LGA 1200 (Socket H5) Tower Black
Model TS100-E11-PI4EAN 4711081886457
50 specifications
- ProcessorIntel® Xeon®
- Weight11.6 kg
- ColourBlack
- Built-in processorNo
- Number of DIMM slots4
- Number of 2.5" bays1
Overview
- Processor
- Intel® Xeon®
- Weight
- 11.6 kg
- Colour
- Black
- Built-in processor
- No
- Number of DIMM slots
- 4
- Number of 2.5" bays
- 1
- Brand
- ASUS
- Category
- Server Barebone
- Model
- TS100-E11-PI4
- Part numbers
- TS100-E11-PI4, 90SF02N1-M000Z0
- EAN / UPC
- 4711081886457
- Also known as
- ASUS TS100-E11-PI4 server barebone Intel C256 LGA 1200 (Socket H5) Tower Black
Specifications
50 specifications in 11 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
| Motherboard chipset | Intel C256 |
| Processor socket | LGA 1200 (Socket H5) |
| Processor manufacturer | Intel |
| Processor family | Intel® Xeon® |
| Number of processors supported | 1 |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 4 |
| Supported memory types | DDR4-SDRAM |
| Supported DIMM module capacities | 8GB, 16GB, 32GB |
| Buffered memory type | Unregistered (unbuffered) |
| Maximum internal memory | 128 GB |
| Supported UDIMM clock speeds | 3200 MHz |
| Memory channels | Dual-channel |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Number of 2.5" bays | 1 |
| Number of 3.5" bays | 3 |
| Storage drive sizes supported | 2.5,3.5,M.2 |
| Supported storage drive types | HDD & SSD |
| SSD form factor | M.2 |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| HDMI ports quantity | 1 |
| VGA (D-Sub) ports quantity | 1 |
| PS/2 ports quantity | 1 |
| Headphone outputs | 1 |
| Microphone in | Yes |
| Number of SATA III connectors | 8 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express slots version | 4.0 |
| Number of M.2 (M) slots | 2 |
Design
| Specification | Value |
|---|---|
| Chassis type | Tower |
| Product colour | Black |
| LED indicators | Yes |
| Reset button | Yes |
| Certification | BSMI, CE, FCC(Class B) |
Power
| Specification | Value |
|---|---|
| Power supply | 300 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 423 mm |
| Height | 435 mm |
| Weight | 11.6 kg |
| Width | 190 mm |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 14.7 kg |
