RS700A-E11-RS12U/10G/4NVME(1600W) Socket SP3 Rack (1U)
Model RS700A-E11-RS12U/10G/4NVME(1600W)Part no. 90SF01E2-M00690EAN 4711081373254
50 specifications
- ProcessorAMD
- Weight18.9 kg
- Built-in processorNo
- Number of DIMM slots32
- Number of storage drives supported14
- On-board graphics card modelAspeed AST2600
Overview
- Processor
- AMD
- Weight
- 18.9 kg
- Built-in processor
- No
- Number of DIMM slots
- 32
- Number of storage drives supported
- 14
- On-board graphics card model
- Aspeed AST2600
- Brand
- ASUS
- Category
- Server Barebone
- Model
- RS700A-E11-RS12U/10G/4NVME(1600W)
- Part number
- 90SF01E2-M00690
- EAN / UPC
- 4711081373254
- Also known as
- ASUS RS700A-E11-RS12U/10G/4NVME(1600W) Socket SP3 Rack (1U)
Specifications
50 specifications in 12 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
| Processor socket | Socket SP3 |
| Processor manufacturer | AMD |
| Processor family | AMD |
| Number of processors supported | 2 |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 32 |
| Supported memory types | DDR4-SDRAM |
| Supported DIMM module capacities | 16GB, 32GB, 64GB, 128MB, 256MB |
| Maximum internal memory | 4 TB |
| Supported RDIMM clock speeds | 2933,3200 MHz |
| Non-ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 14 |
| Storage drive sizes supported | 2.5,M.2 |
| Supported storage drive types | HDD & SSD |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | Aspeed AST2600 |
| On-board graphics card memory | 64 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | 10 Gigabit Ethernet |
| LAN controller | Intel X710-AT2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 2 |
| IPMI LAN (RJ-45) port | Yes |
| VGA (D-Sub) ports quantity | 1 |
| Number of SATA III connectors | 12 |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84714100 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
| LED indicators | HDD, Power |
| On/off switch | Yes |
| Reset button | Yes |
| Cooling type | Active |
| Heat sink included | Yes |
| Number of fans | 8 fan(s) |
Power
| Specification | Value |
|---|---|
| Power supply | 1600 W |
| Number of main power supplies | 1 |
| Redundant power supply (RPS) support | Yes |
| Number of redundant power supplies supported | 1 |
| Number of redundant power supplies installed | 1 |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Input current | 9.4 A |
| 80 PLUS certification | 80 PLUS Platinum |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 60 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 449 mm |
| Height | 43.9 mm |
| Weight | 18.9 kg |
| Width | 842.5 mm |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 23.9 kg |
