ASUS RS700-E12-RS12U Rack (1U) Black, Steel
ASUS

RS700-E12-RS12U Rack (1U) Black, Steel

Model RS700-E12-RS12UPart no. 90SF03S1-M00160EAN 4711636058537

47 specifications
  • ProcessorIntel® Xeon®
  • Weight13.8 kg
  • ColourBlack, Steel
  • Built-in processorNo
  • Number of DIMM slots32
  • Number of storage drives supported14
See all specifications

Overview

Processor
Intel® Xeon®
Weight
13.8 kg
Colour
Black, Steel
Built-in processor
No
Number of DIMM slots
32
Number of storage drives supported
14
Brand
ASUS
Model
RS700-E12-RS12U
Part number
90SF03S1-M00160
EAN / UPC
4711636058537
Also known as
ASUS RS700-E12-RS12U Rack (1U) Black, Steel

Specifications

47 specifications in 12 groups

Processor

Built-in processorNo
Processor manufacturerIntel
Processor familyIntel® Xeon®
Number of processors supported2
Compatible processor seriesIntel® Xeon®

Memory

Number of DIMM slots32
Supported memory typesDDR5-SDRAM
Supported DIMM module capacities16GB, 32GB, 64GB, 128GB
Maximum internal memory4 TB
Supported RDIMM clock speeds6400 MHz

Storage

Number of storage drives supported14
Hot-swap HDD baysYes
Number of 2.5" bays12
Storage drive sizes supported2.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesSerial ATA, Serial Attached SCSI (SAS)

Graphics

On-board graphics card modelAspeed AST2600
On-board graphics card memory64 MB

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Mini DisplayPorts quantity1

Expansion slots

PCI Express slots version5.0
PCI Express x16 (Gen 5.x) slots4
Number of M.2 (M) slots2

Features

Integrated BMC with IPMIYes
Trusted Platform Module (TPM)Yes
Trusted Platform Module (TPM) version2.0

Design

Chassis typeRack (1U)
Product colourBlack, Steel
LED indicatorsYes
Cooling typeActive
Number of fans8 fan(s)
CertificationBSMI, CE, CB, RCM, FCC(Class A), ISED

Power

Power supply2000 W
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
AC input voltage100 - 240 V
AC input frequency50/60 Hz
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)20 - 90%
Operating temperature (T-T)10 - 35 °C
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth483 mm
Height43.2 mm
Weight13.8 kg
Width821.7 mm

Packaging data

Package weight16.7 kg
