ASUS RS520-E9-RS8 V2/4NVME
ASUS

RS520-E9-RS8 V2/4NVME

Model RS520-E9-RS8 V2/4NVMEPart no. 90SF0051-M06780EAN 4711081231073

56 specifications
  • ProcessorIntel® Xeon® Scalable
  • Weight19.7 kg
  • ColourBlack
  • Built-in processorNo
  • Number of DIMM slots16
  • Number of storage drives supported12
See all specifications

Overview

Processor
Intel® Xeon® Scalable
Weight
19.7 kg
Colour
Black
Built-in processor
No
Number of DIMM slots
16
Number of storage drives supported
12
Brand
ASUS
Model
RS520-E9-RS8 V2/4NVME
Part number
90SF0051-M06780
EAN / UPC
4711081231073
Also known as
ASUS RS520-E9-RS8 V2/4NVME Intel® C621 LGA 3647 (Socket P) Rack (2U) Black

Specifications

56 specifications in 14 groups

Processor

Built-in processorNo
Motherboard chipsetIntel® C621
Processor socketLGA 3647 (Socket P)
Processor manufacturerIntel
Processor familyIntel® Xeon® Scalable
Number of processors supported2

Memory

Number of DIMM slots16
Supported memory typesDDR4-SDRAM
Supported DIMM module capacities4GB, 8GB, 32GB, 64GB, 128GB, 256MB
Maximum internal memory4 TB
Supported RDIMM clock speeds2133,2400,2666,2933 MHz

Storage

Number of storage drives supported12
Hot-swap HDD baysYes
Storage drive sizes supported2.5,3.5,M.2
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, Serial ATA III
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2500
On-board graphics card memory64 MB

Network

Ethernet LANYes
Ethernet interface typeGigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports2
IPMI LAN (RJ-45) portYes
VGA (D-Sub) ports quantity2
Number of SATA III connectors11

Expansion slots

PCI Express x8 (Gen 3.x) slots4
PCI Express x16 (Gen 3.x) slots2
Number of M.2 (M) slots2

Features

Compatible operating systemsWindows Server 2019 Windows Server 2016 RHEL 6.8 RHEL 6.9 RHEL 7.X SUSE Enterprise 11 SP4 SUSE Enterprise 12 SP1 SUSE Enterprise 12 SP2 SUSE Enterprise 15 CentOS 6.8 CentOS 7.2 (1511) CentOS 7.3 (1611) Ubuntu 16.04.2 LTS Ubuntu 16.10 Ubuntu 17.04 ESXi 6.5 U1 ESXi 6.7 U3 RHEL 7.X

Logistics data

Harmonized System (HS) code84714100

Design

Chassis typeRack (2U)
Product colourBlack
LED indicatorsHDD, LAN, Power
On/off switchYes
Reset buttonYes

Power

Power supply800 W
Number of main power supplies1
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported1
Number of redundant power supplies installed1
AC input voltage100 - 240 V
AC input frequency47 - 63 Hz
Input current9.4 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 90%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth615 mm
Height88 mm
Weight19.7 kg
Width444 mm

Packaging data

Package weight28 kg
