ASUS RS520-E9-RS12 Intel® C621 LGA 3647 (Socket P) Rack (2U) Black, Stainless steel

ASUS RS520-E9-RS12 Intel® C621 LGA 3647 (Socket P) Rack (2U) Black, Stainless steel

Model RS520-E9-RS12Part no. 90SF0051-M00380EAN 4712900857375

51 specifications
  • ProcessorIntel® Xeon®
  • Weight24.6 kg
  • ColourBlack, Stainless steel
  • Built-in processorNo
  • Number of DIMM slots16
  • Number of storage drives supported14
See all specifications

Overview

Processor
Intel® Xeon®
Weight
24.6 kg
Colour
Black, Stainless steel
Built-in processor
No
Number of DIMM slots
16
Number of storage drives supported
14
Brand
ASUS
Model
RS520-E9-RS12
Part number
90SF0051-M00380
EAN / UPC
4712900857375, 4712900934526
Also known as
ASUS RS520-E9-RS12 Intel® C621 LGA 3647 (Socket P) Rack (2U) Black, Stainless steel

Specifications

51 specifications in 15 groups

Processor

Built-in processorNo
Motherboard chipsetIntel® C621
Processor socketLGA 3647 (Socket P)
Processor familyIntel® Xeon®
Number of processors supported2

Memory

Number of DIMM slots16
Supported memory typesDDR4-SDRAM
Maximum internal memory2 TB
Supported RDIMM clock speeds2400,2666 MHz

Storage

Number of storage drives supported14
Hot-swap HDD baysYes
Number of 2.5" bays2
Number of 3.5" bays12
Storage drive sizes supported2.5,3.5"
Supported storage drive interfacesM.2, Serial ATA III
RAID levels0, 1, 5, 10

Graphics

On-board graphics card modelAspeed AST2500
On-board graphics card memory64 MB

Network

Ethernet LANYes
Ethernet interface typeFast Ethernet, Gigabit Ethernet
Ethernet LAN data rates10,100,1000 Mbit/s
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity2
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity2
Ethernet LAN (RJ-45) ports3
VGA (D-Sub) ports quantity1

Expansion slots

PCI Express x8 slots4
PCI Express x16 slots2
PCI Express x8 (Gen 3.x) slots4
PCI Express x16 (Gen 3.x) slots2

Features

Compatible operating systemsWindows® Server 2016 Windows® Server 2012 R2 RedHat® Enterprise Linux SuSE® Linux Enterprise Server CentOS Ubuntu VMware Citrix XenServer Fedora

Logistics data

Harmonized System (HS) code84714100

Processor special features

Intel Rapid Storage Technology enterpriseYes

Design

Chassis typeRack (2U)
Product colourBlack, Stainless steel
LED indicatorsHDD, Power, Reset
CertificationBSMI, CE, C-Tick, FCC(Class A)

Power

Power supply880 W
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported2
AC input voltage100 - 240 V
AC input frequency47 - 63 Hz
Input current9.4 A

Operational conditions

Operating temperature (T-T)10 - 35 °C
Storage relative humidity (H-H)20 - 90%
Storage temperature (T-T)-40 - 60 °C

Weight & dimensions

Depth444 mm
Height88 mm
Weight24.6 kg
Width615 mm

Packaging data

Package weight30.1 kg
