ASUS RS500A-E9-RS4 Intel SoC Socket SP3 Rack (1U) Black, Silver

ASUS RS500A-E9-RS4 Intel SoC Socket SP3 Rack (1U) Black, Silver

Model RS500A-E9-RS4Part no. 90SF00M1-M00170EAN 4718017140409

48 specifications
  • Weight11 kg
  • ColourBlack, Silver
  • Built-in processorNo
  • Number of DIMM slots16
  • Number of storage drives supported4
  • On-board graphics card modelAspeed AST2500
See all specifications

Overview

Weight
11 kg
Colour
Black, Silver
Built-in processor
No
Number of DIMM slots
16
Number of storage drives supported
4
On-board graphics card model
Aspeed AST2500
Brand
ASUS
Model
RS500A-E9-RS4
Part number
90SF00M1-M00170
EAN / UPC
4718017140409
Also known as
ASUS RS500A-E9-RS4 Intel SoC Socket SP3 Rack (1U) Black, Silver

Specifications

48 specifications in 14 groups

Processor

Built-in processorNo
Motherboard chipsetIntel SoC
Processor socketSocket SP3
Compatible processor seriesAMD EPYC

Memory

Number of DIMM slots16
Supported memory typesDDR4-SDRAM
Maximum internal memory2 TB
Maximum RDIMM memory2 TB
Supported RDIMM clock speeds2133,2400,2666 MHz

Storage

Number of storage drives supported4
Hot-swap HDD baysYes
Number of 2.5" bays4
Number of 3.5" bays4
Storage drive sizes supported2.5,3.5"

Graphics

On-board graphics card modelAspeed AST2500
On-board graphics card memory64 MB

Network

Ethernet LANYes
LAN controllerIntel® I350-AM2

Ports & interfaces

USB 2.0 ports quantity0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
Ethernet LAN (RJ-45) ports3
VGA (D-Sub) ports quantity2

Expansion slots

PCI Express slots version3.0
PCI Express x8 (Gen 3.x) slots1
PCI Express x16 (Gen 3.x) slots1

Features

Backplanes supportYes

Logistics data

Harmonized System (HS) code84714100

Design

Chassis typeRack (1U)
Product colourBlack, Silver
LED indicatorsLAN, Power, Reset
Reset buttonYes
CertificationBSMI, CE, FCC(Class A)

Power

Power supply770 W
Number of main power supplies1
Redundant power supply (RPS) supportYes
Number of redundant power supplies supported1
AC input voltage100 - 240 V
AC input frequency50 - 60 Hz
Input current10 A
80 PLUS certification80 PLUS Platinum

Operational conditions

Operating relative humidity (H-H)20 - 90%
Operating temperature (T-T)10 - 35 °C
Storage temperature (T-T)-40 - 70 °C

Weight & dimensions

Depth444 mm
Height44 mm
Weight11 kg
Width616 mm

Packaging data

Package weight17 kg
