RS500-E9-RS4-U Intel® C621 LGA 3647 (Socket P) Rack (2U) Black
Model RS500-E9-RS4-UPart no. 90SF00N1-M00710EAN 4718017293730
44 specifications
- ProcessorIntel® Xeon® Scalable
- Weight11 kg
- ColourBlack
- Built-in processorNo
- Number of DIMM slots16
- Number of storage drives supported4
Overview
- Processor
- Intel® Xeon® Scalable
- Weight
- 11 kg
- Colour
- Black
- Built-in processor
- No
- Number of DIMM slots
- 16
- Number of storage drives supported
- 4
- Brand
- ASUS
- Category
- Server Barebone
- Model
- RS500-E9-RS4-U
- Part number
- 90SF00N1-M00710
- EAN / UPC
- 4718017293730
- Also known as
- ASUS RS500-E9-RS4-U Intel® C621 LGA 3647 (Socket P) Rack (2U) Black
Specifications
44 specifications in 14 groups
Processor
| Specification | Value |
|---|---|
| Built-in processor | No |
| Motherboard chipset | Intel® C621 |
| Processor socket | LGA 3647 (Socket P) |
| Processor family | Intel® Xeon® Scalable |
| Number of processors supported | 2 |
| Compatible processor series | Intel® Xeon® |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 16 |
| Supported memory types | DDR4-SDRAM |
| Maximum internal memory | 2 TB |
| Supported RDIMM clock speeds | 2133,2400,2666 MHz |
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 4 |
| Hot-swap HDD bays | Yes |
| Storage drive sizes supported | 2.5,3.5" |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, Serial ATA III, Serial Attached SCSI (SAS) |
Graphics
| Specification | Value |
|---|---|
| On-board graphics card model | Aspeed AST2500 |
| On-board graphics card memory | 64 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet, Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| LAN controller | Intel® I350-AM2 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| IPMI LAN (RJ-45) port | Yes |
| VGA (D-Sub) ports quantity | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x8 (Gen 3.x) slots | 1 |
| PCI Express x16 (Gen 3.x) slots | 1 |
| Number of M.2 (M) slots | 2 |
Features
| Specification | Value |
|---|---|
| Compatible operating systems | Windows Server 2016 RedHat Enterprise Linux SuSE Linux Enterprise Server CentOS Ubuntu VMware Citrix XenServer |
Logistics data
| Specification | Value |
|---|---|
| Harmonized System (HS) code | 84714100 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (2U) |
| Product colour | Black |
| LED indicators | Yes |
| On/off switch | Yes |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 444 mm |
| Height | 44 mm |
| Weight | 11 kg |
| Width | 616 mm |
Packaging data
| Specification | Value |
|---|---|
| Package weight | 17 kg |
Other features
| Specification | Value |
|---|---|
| Optical drive supported | Yes |
