RS300-E12-RS4 Intel C262 LGA 1700 Rack (1U) Silver
Model RS300-E12-RS4Part no. 90SF03A1-M00070EAN 4711387500378
37 specifications
- Weight15.2 kg
- ColourSilver
- Motherboard chipsetIntel C262
- Number of DIMM slots4
- Number of storage drives supported8
- Ethernet LANYes
Overview
- Weight
- 15.2 kg
- Colour
- Silver
- Motherboard chipset
- Intel C262
- Number of DIMM slots
- 4
- Number of storage drives supported
- 8
- Ethernet LAN
- Yes
- Brand
- ASUS
- Category
- Server Barebone
- Model
- RS300-E12-RS4
- Part number
- 90SF03A1-M00070
- EAN / UPC
- 4711387500378
- Also known as
- ASUS RS300-E12-RS4 Intel C262 LGA 1700 Rack (1U) Silver
Specifications
37 specifications in 10 groups
Processor
| Specification | Value |
|---|---|
| Motherboard chipset | Intel C262 |
| Processor socket | LGA 1700 |
| Number of processors supported | 1 |
| Intel Xeon series | 6300 |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 4 |
| Supported memory types | DDR5-SDRAM |
| Supported DIMM module capacities | 8GB, 16GB, 32GB |
| Maximum internal memory | 128 GB |
| Supported RDIMM clock speeds | 4400,4000,3600 MHz |
| Memory channels | Dual-channel |
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 8 |
| Hot-swap HDD bays | Yes |
| Number of 3.5" bays | 4 |
| Storage drive sizes supported | 3.5" |
| Supported storage drive types | HDD & SSD |
| Supported storage drive interfaces | M.2, Serial ATA III, Serial Attached SCSI (SAS) |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 2 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 3 |
| Ethernet LAN (RJ-45) ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| COM ports quantity | 1 |
| Number of SATA III connectors | 8 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x16 (Gen 5.x) slots | 1 |
Design
| Specification | Value |
|---|---|
| Chassis type | Rack (1U) |
| Product colour | Silver |
| LED indicators | Power, Reset, HDD |
Power
| Specification | Value |
|---|---|
| Power supply | 450 W |
| 80 PLUS certification | 80 PLUS Platinum |
Operational conditions
| Specification | Value |
|---|---|
| Operating temperature (T-T) | 10 - 35 °C |
| Storage relative humidity (H-H) | 20 - 90% |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 439.5 mm |
| Height | 44 mm |
| Weight | 15.2 kg |
| Width | 497 mm |
