RS100-E5/PI2 server barebone Intel® 3200 LGA 775 (Socket T)
Model RS100-E5/PI2Part no. 90S-S4M003CEZEAN 4719543304426
31 specifications
- ProcessorIntel
- Weight6.5 kg
- Motherboard chipsetIntel® 3200
- Number of DIMM slots4
- Number of storage drives supported2
- Maximum graphics card memory32 MB
Overview
- Processor
- Intel
- Weight
- 6.5 kg
- Motherboard chipset
- Intel® 3200
- Number of DIMM slots
- 4
- Number of storage drives supported
- 2
- Maximum graphics card memory
- 32 MB
- Brand
- ASUS
- Category
- Server Barebone
- Model
- RS100-E5/PI2
- Part numbers
- 90S-S4M003CEZ, RS100-E5/PI2, 90S-S4M001CEZ, 90S4M001CET, 90SS4M001CEZ, 90S-S4M002CEZ +2 more
- EAN / UPC
- 4719543304426, 610839665518, 4719543659892, 4719543660034 +5 more
- Also known as
- ASUS RS100-E5/PI2 server barebone Intel® 3200 LGA 775 (Socket T)
Specifications
31 specifications in 13 groups
Processor
| Specification | Value |
|---|---|
| Motherboard chipset | Intel® 3200 |
| Processor socket | LGA 775 (Socket T) |
| Processor family | Intel |
| Supported processor frequency (max) | 1.333 GHz |
Memory
| Specification | Value |
|---|---|
| Number of DIMM slots | 4 |
| Maximum internal memory | 8 GB |
| ECC | Yes |
Storage
| Specification | Value |
|---|---|
| Number of storage drives supported | 2 |
| Storage controller | Intel ICH7R |
| RAID levels | 0, 1 |
Graphics
| Specification | Value |
|---|---|
| Maximum graphics card memory | 32 MB |
Network
| Specification | Value |
|---|---|
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| LAN controller | Broadcom BCM5721 |
Ports & interfaces
| Specification | Value |
|---|---|
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Serial ports quantity | 1 |
| PS/2 ports quantity | 2 |
Expansion slots
| Specification | Value |
|---|---|
| PCI Express x16 slots | 1 |
Features
| Specification | Value |
|---|---|
| Compatible operating systems | Windows Server 2003 R2 Enterprise (32/64 bit), RedHat Enterprise Linux AS5.0 (32/64 bit), SuSE Linux Enterprise Server 10 (32/64 bit) |
Power
| Specification | Value |
|---|---|
| Power supply | 220 W |
Operational conditions
| Specification | Value |
|---|---|
| Operating relative humidity (H-H) | 20 - 90% |
| Operating temperature (T-T) | 10 - 35 °C |
| Storage temperature (T-T) | -40 - 70 °C |
Weight & dimensions
| Specification | Value |
|---|---|
| Depth | 43.4 mm |
| Height | 380 mm |
| Weight | 6.5 kg |
| Width | 430 mm |
Packaging data
| Specification | Value |
|---|---|
| Bundled software | ASWM2.0 |
Other features
| Specification | Value |
|---|---|
| Drive bays | 2 x SATA2 |
